Plate 5
Plate 5.--A, Peel print (x3.0) of upper Bennett limestone from Elmdale section. Wavy dark lines are sheetlike algal crusts (Anchicodium?). Note crust fragments in lower and upper left of picture. B, Peel print (x3.5) of Bennett limestone from Highway 38 section. Note wavy sheetlike algal crusts in lower half of picture and broken algal crusts with brachiopod fragments in upper half. Arrows point to top of bed. [Note: This image is scanned to be twice in size to that in the published book to show more detail.]
