Kansas Geological Survey Publications Sample

Hydrgeology and Geochemistry of Glacial Deposits in Northeastern Kansas

Jane E. Denne, Rachel E. Miller, Lawrence R. Hathaway, Howard G. O'Connor and William C. Johnson

Bulletin 229
1998
127 pages, 89 figures, map in pocket,
references, and an index
cover thumbnail
A full online version of this publication is not available. Copies of this publication are available from the publications office of the Kansas Geological Survey (785-864-3965). The cost is $25.00, plus sales tax, shipping, and handling.

Abstract

Twelve counties (Atchison, Brown, Doniphan, Douglas, Jackson, Jefferson, Johnson, Leavenworth, Nemaha, Shawnee, Wabaunsee, and Wyandotte) in northeastern Kansas were glaciated during the Pleistocene Epoch. The glacial deposits consist of till, fluvial, loess, and lacustrine deposits locally totalling thicknesses of 400 ft (120 m). A major buried valley 3 mi (5 km) wide, 400 ft (120 m) deep, and 75 mi (120 km) long trends eastward across southern Nemaha, northern Jackson, and central Atchison counties. Several smaller tributary valleys can be identified in Atchison, Nemaha, Brown, Jackson, and Jefferson counties. Other buried valleys generally trend southward to the Kansas River valley or northward into Nebraska and Missouri.

The glacial deposits filling the buried valleys locally are clayey. However, most valleys contain at least some water-bearing sand and gravel. Wells drilled into the best water-bearing sand and gravel deposits may yield as much as 900 gallons per minute (gpm; 0.06 m3/S), but less than 500 gpm (0.03 m3/S) is more common. The alluvial deposits of the Kansas and Missouri river valleys are the major sources of ground water in northeastern Kansas. Wells in these aquifers may have yields of 5,000 gpm (0.3 m3/S), but yields are more commonly less than 3,000 gpm (0.2 m3/S).

We analyzed data from 80 pump tests using computer programs to find the best fit for transmissivity (T) and storage (S) values on glacial, alluvial, and bedrock aquifers. Transmissivities in the Missouri River valley alluvium ranged from 200,000 gallons per day per foot (gpd/ft) to 600,000 gpd/ft (2,000-7,000 m2/d), and storage values were between 0.001 and 0.0004. Tests in the Kansas River valley alluvium indicated transmissivities in the range 50,000-600,000 gpd/ft (600-7,000 m2/d) and storage values of 0.03. In the main buried valley across northeastern Kansas, the glacial deposits had T and S values of 2,500-25,600 gpd/ft (31.0-318 m2/d) and 0.00002-0.002, respectively. In the smaller buried valleys the glacial deposits had T values ranging from 1,500 gpd/ft to 100,000 gpd/ft (19-1,200 m2/d).

Because of increasing population size in northeastern Kansas, appropriations of water for public and industrial water supplies have been increasing. Most of the pumpage comes from wells in the Kansas and Missouri river valleys. However, in 1981 the Division of Water Resources reported allocations of 1,466 acre-ft of water from wells tapping glacial aquifers associated with the main buried channel across Nemaha, Jackson, and Atchison counties and an additional 837 acre-ft from tributaries associated with the main buried channel. Nemaha County has the largest appropriation of water from the glacial aquifer (1,549 acre-ft/yr in 1983), and Wyandotte County has the largest appropriation of water from the alluvial aquifers (54,250 acre-ft/yr in 1983). Shawnee County has the largest number of ground-water appropriation rights (217). In 1981, for the 12-county study area, the Division of Water Resources found that 773 wells have ground-water appropriation rights. These 773 wells have appropriation rights for 140,484 acre-ft of water from alluvial aquifers, 5,290 acre-ft from glacial aquifers, and 2,146 acre-ft from Pennsylvanian and Permian rock aquifers.

Maps for each county show the depth to bedrock, total thickness of Pleistocene sand and gravel deposits, estimated yield of wells, depth to water in wells and test holes, and the saturated thickness of Pleistocene deposits. A bedrock topographic map for the twelve counties was prepared from outcrop data and information from more than 5,000 water well, oil and gas, and test-hole logs. Ground waters from alluvial deposits are hard calcium bicarbonate waters that may have iron concentrations of several milligrams per liter. Sand and gravel associated with the glacial deposits generally yield hard calcium bicarbonate waters and may contain appreciable amounts of iron, manganese, sulfate, and chloride locally. Nitrate concentrations above 45 mg/L are noted in a number of wells of varying depth and aquifer source.
