Kansas Geological Survey, Special Distribution Publication 22, originally published in 1965
Originally published in 1965 as Kansas Geological Survey Special Distribution Publication No. 22. This is, in general, the original text as published. The information has not been updated. An Adobe Acrobat version of the book is also available (11.8 MB).
Prepared as part of the cooperative ground-water program in Kansas conducted by the United States Geological Survey, the State Geological Survey of Kansas, the Division of Water Resources of the Kansas State Board of Agriculture, and the Environmental Health Services of the Kansas State Department of Health.
The logs of 369 wells and test holes in Sedgwick County, Kansas, are given on the following pages. The samples from test holes drilled by the State Geological Survey of Kansas and a part of those drilled by private contractors and the City of Wichita were examined and logged in the field. The logs that are designated "Sample logs" were prepared after microscopic examination of the samples in the laboratory and comparison with the field log.
A (T) following the figure for "altitude of land surface" indicates the altitude was determined from modern 7 1/2-minute topographic maps having 10-foot contour intervals. Other altitudes were determined by field measurements.
Locations of these wells and test holes can be found on Plate 1 of "Geology and Ground-Water Resources of Sedgwick County, Kansas," by C. W. Lane and D. E. Miller, Bulletin 176, published by the State Geological Survey of Kansas in 1965.
Bayne, C. K., 1962, Geology and ground-water resources of Cowley County, Kansas: Kansas Geol. Survey, Bull. 158, 219 p. [available online]
Lane, C. W., 1960, Geology and ground-water resources of Kingman County, Kansas: Kansas Geol. Survey, Bull. 144, 174 p. [available online]
Williams, C. C., and Lohman, S. W., 1949, Geology and ground-water resources of a part of south-central Kansas with special reference to the Wichita municipal water supply: Kansas Geol. Survey, Bull. 79, 455 p. [available online]
T. 25 S. || T. 26 S. || T. 27 S. || T. 28 S. || T. 29 S. || T. 30 S.
25-1E-5ddd--Sample log of test hole in SE SE SE sec. 5, T 25 S, R 1 E, on north side of road by first small hedge tree; 150 feet west of Highway 81; augered September 1958. Altitude of land surface, 1,409.2 feet; depth to water, 20-25 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Illinoisan stages (loess) | |||
![]() |
![]() |
![]() |
Silt, sandy, dark-tan | 5 | 5 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Sand, fine to coarse, some fine gravel; quartzose, very silty, tan | 5 | 10 |
![]() |
![]() |
![]() |
Sand, fine to coarse, some fine gravel, very silty, tan; quartzose | 5 | 15 |
![]() |
![]() |
![]() |
Sand, fine to coarse, mostly fine to medium; some shale fragments, with streaks of tan silt | 5 | 20 |
![]() |
![]() |
![]() |
Clay, silty, reddish-brown, and reddish-tan sandy silt | 5 | 25 |
![]() |
![]() |
![]() |
Silt, very sandy at base, light-tan | 5 | 30 |
![]() |
![]() |
![]() |
Silt, sandy, light-tan | 8 | 38 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 1 | 39 |
25-1E-19abb--Sample log of test hole in NW NW NE sec. 19, T 25 S, R 1 E, on south side of road, 5 feet east of half-section fence; augered September 1958. Altitude of land surface, 1,379.0 feet; depth to water, 13.3 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Illinoisan stages (loess and slope deposits) | |||
![]() |
![]() |
![]() |
Silt, sandy, dark reddish-tan, some caliche | 5 | 5 |
![]() |
![]() |
![]() |
Silt, sandy, dark-tan | 10 | 15 |
![]() |
![]() |
![]() |
Sand, fine to coarse, very silty; some thin gray silt streaks | 5 | 20 |
![]() |
![]() |
![]() |
Silt, very sandy, light grayish-tan | 5 | 25 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 5 | 30 |
25-1E-22bbb--Sample log of test hole in NW NW NW sec. 22, T 25 S, R 1 E, on east side of road, 60 feet south of center line of east-west road; augered September 1958. Altitude of land surface, 1,437.2 feet; depth to water, 13.5 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Illinoisan stages (loess) | |||
![]() |
![]() |
![]() |
Silt, dark-gray | 5 | 5 |
![]() |
![]() |
![]() |
Silt, sandy, reddish-tan to light-tan; some caliche pebbles | 5 | 10 |
![]() |
![]() |
![]() |
Silt, light-tan; some caliche pebbles | 5 | 15 |
![]() |
![]() |
![]() |
Silt, sandy, light grayish-tan; some caliche pebbles | 8 | 23 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 1 | 24 |
25-1E-29aab--Sample log of test hole in NW NE NE sec. 29, T 25 S, R 1 E, on south side of road, opposite farm lane, 0.2 mile west of Highway 81; augered September 1958. Altitude of land surface, 1,399.2 feet; dry hole. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Illinoisan stages (loess) | |||
![]() |
![]() |
![]() |
Silt, reddish-brown | 5 | 5 |
![]() |
![]() |
![]() |
Silt, sandy, reddish-tan | 7 | 12 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 1 | 13 |
25-1E-30ddd--Sample log of test hole in SE SE SE sec. 30, T 25 S, R 1 E, on west road shoulder, 60 feet north of center line of east-west road; augered September 1958. Altitude of land surface, 1,368.5 feet; depth to water, 17.2 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
![]() |
![]() |
![]() |
Road fill | 3 | 3 |
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Illinoisan stages (loess) | |||
![]() |
![]() |
![]() |
Silt, sandy, reddish-brown | 2 | 5 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Sand, fine to medium, silty | 5 | 10 |
![]() |
![]() |
![]() |
Sand, fine to coarse, mostly fine | 5 | 15 |
![]() |
![]() |
![]() |
Sand, fine to coarse; quartzose; much tan silt near base | 5 | 20 |
![]() |
![]() |
![]() |
Sand, fine to coarse, mostly fine to medium, silty, tan | 7 | 27 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 1 | 28 |
25-1E-33aaa--Sample log of test hole in NE NE NE sec. 33, T 25 S, R 1 E, on east side of road, 100 feet south of east-west road; augered September 1958. Altitude of land surface, 1,389.0 feet; dry hole. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Illinoisan stages (loess) | |||
Permian | |||||
![]() |
![]() |
![]() |
Silt, very sandy, clayey, dark reddish-tan | 7 | 7 |
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 1 | 8 |
25-1W-1bbb--Sample log of test hole in NW NW NW sec. 1, T 25 S, R 1 W, on east side of road, 50 feet south of center line of east-west road; augered September 1958. Altitude of land surface 1,390.3 feet; depth to water, 24.4 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Illinoisan stages (loess) | |||
![]() |
![]() |
![]() |
Silt, sandy, dark-tan | 5 | 5 |
![]() |
![]() |
![]() |
Silt, sandy, reddish-tan; contains caliche | 5 | 10 |
![]() |
![]() |
![]() |
Silt, some sand, reddish-tan | 5 | 15 |
![]() |
![]() |
![]() |
Silt, some sand, reddish-tan; some caliche pebbles | 5 | 20 |
![]() |
![]() |
![]() |
Silt, tan; some caliche pebbles | 5 | 25 |
![]() |
![]() |
![]() |
Silt, tan; very sandy at base | 5 | 30 |
![]() |
![]() |
![]() |
Silt, very sandy, grayish-tan | 4 | 34 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Sand, very silty, gray to pink | 4 | 38 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, hard, no returns from bit | 5 | 43 |
25-1W-4bbc--Driller's log of test hole in SW NW NW sec. 4, T 25 S, R 1 W; augered May 1955. Altitude of land surface, 1,369.6 feet; depth to water, 20.9 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, dark-gray | 2 | 2 |
![]() |
![]() |
![]() |
Silt, sandy, tan; some caliche pebbles | 2 | 4 |
![]() |
![]() |
![]() |
Silt, sandy, dark-tan | 5 | 9 |
![]() |
![]() |
![]() |
Silt, dark-gray | 3 | 12 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 1 | 13 |
![]() |
![]() |
![]() |
Silt, sandy, gray | 6 | 19 |
![]() |
![]() |
![]() |
Silt, clayey, gray | 5 | 24 |
![]() |
![]() |
![]() |
Silt, sandy and clayey, gray | 5 | 29 |
25-1W-4cbb--Sample log of test hole in NW NW SW sec. 4, T 25 S, R 1 W; augered May 1955. Altitude of land surface, 1,372.8 feet; depth to water, 18.7 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Road fill | 3 | 3 |
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, tan | 1 | 4 |
![]() |
![]() |
![]() |
Sand, fine to coarse, much fine to medium, some fine gravel, arkosic; some grayish-tan silt | 15 | 19 |
![]() |
![]() |
![]() |
Sand, fine to coarse with fine to coarse gravel; arkosic, much sandy grayish-tan silt | 5 | 24 |
![]() |
![]() |
![]() |
Silt, very sandy, grayish-tan; some sand and gravel | 5 | 29 |
![]() |
![]() |
![]() |
Silt, very sandy, light tannish-gray | 10 | 39 |
25-1W-4ccb--Driller's log of test hole in NW SW SW sec. 4, T 25 S, R 1 W; augered May 1955. Altitude of land surface, 1,373.5 feet; depth to water, 21.1 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Road fill | 3 | 3 |
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Sand, fine | 1 | 4 |
![]() |
![]() |
![]() |
Sand, fine to coarse, some fine to medium; arkosic, gray | 24 | 28 |
![]() |
![]() |
![]() |
Silt, clayey, gray | 6 | 34 |
25-1W-6ccc--Sample log of test hole M34T in SW SW SW sec. 6, T 25 S, R 1 W; drilled by Layne-Western Co, for the City of Wichita, 1947. Altitude of land surface, 1,383.6 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, grayish-tan | 5 | 5 |
![]() |
![]() |
![]() |
Silt, sandy, some fine gravel, grayish-tan | 5 | 10 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine to medium gravel; arkosic | 10 | 20 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine to coarse gravel; arkosic | 5 | 25 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine to coarse gravel; arkosic with streaks of sandy gray silt | 10 | 35 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel | 20 | 55 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine to coarse gravel; streaks of gray, carbonaceous, sandy silt | 7 | 62 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Silt, sandy, grayish-tan to gray; some caliche and bone fragments | 8 | 70 |
![]() |
![]() |
![]() |
Silt, grayish-tan to gray; some caliche, thin streaks of fine to coarse sand and fine gravel, quartzose | 15 | 85 |
![]() |
![]() |
![]() |
Silt, sandy, grayish-tan; some caliche pebbles, streaks of gray quartz sand | 5 | 90 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine gravel; quartzose | 5 | 95 |
![]() |
![]() |
![]() |
Silt,sandy, light gray | 5 | 100 |
![]() |
![]() |
![]() |
Sand, fine to coarse and fine gravel, yellowish-gray; quartzose | 20 | 120 |
![]() |
![]() |
![]() |
Sand, fine to coarse and fine gravel, yellowish-gray; quartzose, streaks of sandy, gray to tan, clayey silt | 10 | 130 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine gravel, yellowish-gray; quartzose | 10 | 140 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine gravel, yellowish-gray; quartzose, clayey tan silt streaks | 7 | 147 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 3 | 150 |
25-1W-7baa--Sample log of test hole M35T in NE NE NW sec. 7, T 25 S, R 1 w; drilled by Layne-Western Co. for the City of Wichita, 1947. Altitude of land surface, 1,383.1 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, tan | 5 | 5 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine to coarse gravel; arkosic | 10 | 15 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine to coarse gravel; arkosic, some grayish-tan sandy silt | 10 | 25 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine to coarse gravel; arkosic | 39 | 64 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Sand, fine to coarse, fine gravel, yellowish-gray; quartzose, some sandy gray silt in lower 5 feet | 11 | 75 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine gravel, yellowish-tan; quartzose, streaks of sandy light-gray silt with caliche pebbles present | 10 | 85 |
![]() |
![]() |
![]() |
Silt, sandy, light grayish-tan; caliche pebbles present | 10 | 95 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine gravel; gray, quartzose, some thin gray sandy silt streaks | 12 | 107 |
![]() |
![]() |
![]() |
Silt, sandy, grayish-tan; sand streaks present | 5 | 112 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine gravel, yellowish-gray; quartzose | 5 | 117 |
![]() |
![]() |
![]() |
Silt, sandy, light-gray; many streaks of fine to coarse sand and fine gravel; bedrock rubble in lower 15 feet | 21 | 138 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale | 4 | 142 |
25-1W-7bcc--Sample log of well M36 in SW SW NW sec. 7, T 25 S, R 1 W; drilled by Layne-Western Co. for the City of Wichita, January 1958. Altitude of land surface, 1,385.4 feet; depth to water, 26.8 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, dark-tan; some caliche | 7 | 7 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine gravel; arkosic | 3 | 10 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine gravel; arkosic, much dark and quartz gravel | 10 | 20 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine to coarse gravel; arkosic | 10 | 30 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine to coarse gravel | 23 | 53 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine to medium gravel, gray; arkosic, much gray granite, gray quartz and other dark rocks, streaks of gray silt | 7 | 60 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Silt, sandy, clayey, gray to grayish-tan | 5 | 65 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel, grayish-pink; arkosic, much quartz | 5 | 70 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; arkosic, streaks of grayish-tan clayey silt, some caliche pebbles in lower 5 feet | 10 | 80 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; all quartz, many caliche pebbles | 5 | 85 |
![]() |
![]() |
![]() |
Silt, sandy, dark-gray to tan | 5 | 90 |
![]() |
![]() |
![]() |
Silt, sandy, light grayish-tan | 15 | 105 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; some dark and arkosic gravel; mostly quartz; quartzite pebbles present | 5 | 110 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine gravel; dark and arkosic gravel, white sandstone fragments; some sandy, tan silt and tan clay in lower 5 feet | 15 | 125 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine gravel; dark and arkosic gravel, many large siltstone fragments | 15 | 140 |
![]() |
![]() |
![]() |
Sand, fine to coarse; much gray and yellow silt and gray and pink clay; no clay in lower 5 feet | 10 | 150 |
![]() |
![]() |
![]() |
Silt, sandy, clayey, light grayish-tan to pink | 5 | 155 |
![]() |
![]() |
![]() |
Silt, sandy, light grayish-tan to pink | 10 | 165 |
![]() |
![]() |
![]() |
Silt, sandy, clayey, tan, pink and grayish- tan | 10 | 175 |
![]() |
![]() |
![]() |
Sandy fine to coarse, and fine gravel; yellowish-tan; mostly quartz, some arkosic | 5 | 180 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, yellowish-tan; some Cretaceous ironstone | 3 | 183 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, weathered | 7 | 190 |
25-1W-9bcc--Driller's log of test hole in SW SW NW sec. 9, T 25 S, R 1 W; augered May 1955. Altitude of land surface 1,370. 2 feet; depth to water, 15.6 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Road fill | 2 | 2 |
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Sand, fine to coarse | 4 | 6 |
![]() |
![]() |
![]() |
Silt, clayey | 2 | 8 |
![]() |
![]() |
![]() |
Sand, fine to coarse | 2 | 10 |
![]() |
![]() |
![]() |
Silt | 2 | 12 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic, much quartz | 5 | 17 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, gray | 7 | 24 |
![]() |
![]() |
![]() |
Silt, clayey, gray | 1 | 25 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 4 | 29 |
![]() |
![]() |
![]() |
Sand, fine to coarse, silty, gray | 16 | 45 |
25-1W-9ccc--Sample log of test hole in SW SW SW sec. 9, T 25 S, R 1 W; augered 1955. Altitude of land surface, 1,3?2.5 feet; depth to water, 18.9 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Road fill | 3 | 3 |
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, tan | 3 | 6 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; arkosic, some tan silt | 8 | 14 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; some tan sandy silt | 35 | 49 |
25-1W-9daa--Driller's log of test hole in NE NE SE sec. 9, T 25 S, R 1 W; augered May 1955. Altitude of land surface, 1,359.4 feet; depth to water, 18.5 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Road fill | 3 | 3 |
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, tan | 3 | 6 |
![]() |
![]() |
![]() |
Silt, dark-gray | 3 | 9 |
![]() |
![]() |
![]() |
Sand, fine to medium | 10 | 19 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel, pink; arkosic | 30 | 49 |
25-1W-9dcc--Driller's log of test hole in SW SW SE sec. 9, T 25 S, R 1 W; augered May 1955. Altitude of land surface, 1,369.7 feet; depth to water, 18.5 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Road fill | 2 | 2 |
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, dark-gray | 2 | 4 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel, pink; arkosic | 20 | 24 |
![]() |
![]() |
![]() |
Silt, clayey, brown to gray; much carbonaceous material | 5 | 29 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, silty, gray | 16 | 45 |
25-1W-10ccc--Sample log of test hole for observation well 125 in SW SW SW sec. 10, T 25 S, R 1 w; drilled July 1955. Altitude of land surface, 1,360.7 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, dark-gray | 5 | 5 |
![]() |
![]() |
![]() |
Silt, sandy, medium-gray | 10 | 15 |
![]() |
![]() |
![]() |
Silt, clayey, sandy, light- to medium-gray | 9 | 24 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Sand, fine to coarse; quartzose, some white, and a little pink feldspar | 6 | 30 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; some white and pink feldspar | 15 | 45 |
![]() |
![]() |
![]() |
Sand, fine to coarse, more fine to medium gravel; gravel is feldspar, some caliche pebbles | 5 | 50 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine to medium feldspar gravel; many streaks of sandy gray silt with caliche pebbles | 15 | 65 |
![]() |
![]() |
![]() |
Sand, fine to coarse; quartzose, many streaks of sandy, gray silt with caliche | 7 | 72 |
![]() |
![]() |
![]() |
Silt, very sandy, light-tan | 5 | 77 |
![]() |
![]() |
![]() |
Sand, fine to coarse; quartzose | 1 | 78 |
![]() |
![]() |
![]() |
Silt, sandy, light-tan | 2 | 80 |
![]() |
![]() |
![]() |
Sand, fine to coarse, mostly fine to medium; many streaks of sandy tan silt | 12 | 92 |
![]() |
![]() |
![]() |
Sand, fine to coarse, grayish-tan; quartzose | 5 | 97 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 2 | 99 |
![]() |
![]() |
![]() |
Sand, fine to coarse, grayish-tan; quartzose | 6 | 105 |
![]() |
![]() |
![]() |
Sand, fine to coarse and fine gravel, grayish-tan; quartzose; shale fragments from Dakota Formation and Permian System | 15 | 120 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine gravel, grayish-tan; streaks of sandy tan silt | 3 | 123 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 8 | 131 |
25-1W-13aaa--Sample log of test hole in NE NE NE sec. 13, T 25 S, R 1 W, on south side of road, 75 feet west of center line of north-south road; augered September 1958. Altitude of land surface, 1,5?3.3 feet; depth to water 21.5 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, reddish-brown | 10 | 10 |
![]() |
![]() |
![]() |
Silt, slightly sandy, reddish-brown | 5 | 15 |
![]() |
![]() |
![]() |
Silt, sandy, dark-tan | 5 | 20 |
![]() |
![]() |
![]() |
Sand, fine to coarse, very silty, tan | 13 | 33 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 1 | 34 |
25-1W-13bbb--Sample log of test hole in NW NW NW sec. 13, T 25 S, R 1 W, on south side of road, 100 feet east of north-south road, under tree; augered September 1958. Altitude of land surface, 1,369.6 feet; depth to water, 17.6 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, grayish-brown | 5 | 5 |
![]() |
![]() |
![]() |
Silt, sandy, clayey, dark grayish-tan | 5 | 10 |
![]() |
![]() |
![]() |
Silt, sandy, grayish-tan to tan; very sandy at base | 5 | 15 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 2 | 17 |
![]() |
![]() |
![]() |
Sand, fine to coarse and fine gravel; arkosic, and much tan silt | 8 | 25 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; arkosic, some tan silt | 19 | 44 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 44 |
25-1W-16aaa--Driller's log of test hole in NE NE NE sec. 16, T 25 S, R 1 W; augered May 1955. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
![]() |
![]() |
![]() |
Road fill | 3 | 3 |
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, tan | 3 | 6 |
![]() |
![]() |
![]() |
Silt, dark-gray | 2 | 8 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 6 | 14 |
![]() |
![]() |
![]() |
Silt, sandy, grayish-green; organic, with smell of decaying vegetation | 5 | 19 |
![]() |
![]() |
![]() |
Silt, clayey, brown; organic | 5 | 24 |
![]() |
![]() |
![]() |
Silt, brown | 5 | 29 |
![]() |
![]() |
![]() |
Silt, clayey, grayish-green | 5 | 34 |
![]() |
![]() |
![]() |
Sand, fine to coarse, silty, gray | 15 | 49 |
25-1W-16daa--Driller's log of test hole in NE NE SE sec. 16, T 25 S, R 1 W; augered May 1955. Altitude of land surface, 1,361.4 feet; depth to water 18.6 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Road fill | 3 | 3 |
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, tan | 1 | 4 |
![]() |
![]() |
![]() |
Sand, fine to medium | 5 | 9 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel, pink; arkosic | 19 | 28 |
![]() |
![]() |
![]() |
Silt, clayey, gray; contains carbonaceous material | 4 | 32 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; quartzose, gray | 17 | 49 |
25-1W-17cbb--Sample log of test hole 39T in NW NW SW sec. 17, T 25 S, R 1 W; drilled by Layne-Western Co. for the City of Wichita, December 1957. Altitude of land surface, 1,374.7 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, tan; few caliche pebbles | 7 | 7 |
![]() |
![]() |
![]() |
Sand, fine to medium; arkosic; contains much mica and magnetite | 3 | 10 |
![]() |
![]() |
![]() |
Silt, sandy, clayey, light-gray | 9 | 19 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel | 2 | 21 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic | 24 | 45 |
![]() |
![]() |
![]() |
Sand, fine to coarse, some fine to medium gravel | 5 | 50 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel | 5 | 55 |
![]() |
![]() |
![]() |
Sand, fine to coarse; much fine to medium gravel in upper 5 feet | 10 | 65 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; 90 percent quartz, lower 5 feet contains mortar bed fragments | 20 | 85 |
![]() |
![]() |
![]() |
Sand, fine to coarse, much fine gravel | 3 | 88 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 1 | 89 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; 90 percent quartz | 20 | 109 |
![]() |
![]() |
![]() |
Silt, very sandy, gray | 7 | 116 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine to coarse gravel; arkosic, some fragments of Cretaceous material, and streaks of grayish-tan silt | 11 | 127 |
![]() |
![]() |
![]() |
Silt, sandy, gray | 2 | 129 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; much derived from Cretaceous rocks; thin streaks of grayish-tan clay and silt | 16 | 145 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine to medium gravel; streaks of grayish-tan silt | 10 | 155 |
![]() |
![]() |
![]() |
Clay, gray | 4 | 159 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, dark-gray | 11 | 170 |
25-1W-17ccc--Sample log of test hole 40T in SW SW SW sec. 17, T 25 S, R 1 W; drilled by Layne-Western Co. for the City of Wichita, December 1957. Altitude of land surface, 1,373.7 feet; depth to water, 15.5 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Soil, sandy, gray-brown | 2 | 2 |
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, grayish-tan; some caliche | 4 | 6 |
![]() |
![]() |
![]() |
Sand, fine to coarse and fine to coarse gravel; arkosic | 34 | 40 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic | 11 | 51 |
![]() |
![]() |
![]() |
Silt, gray | 1 | 52 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; arkosic, contains dark gravel | 8 | 60 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Sand, fine to coarse, some fine gravel; 95 percent quartz | 3 | 63 |
![]() |
![]() |
![]() |
Silt, gray to tan | 1 | 64 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; quartz, some patches of arkosic gravel | 6 | 70 |
![]() |
![]() |
![]() |
Silt, sandy, clayey, light grayish-tan; very sandy in lower 4 feet | 14 | 84 |
![]() |
![]() |
![]() |
Sand, fine to coarse, some fine gravel, yellowish-tan; 95 percent quartz; some material derived from Dakota Formation, some tan silt in lower 5 feet | 16 | 100 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine gravel, yellowish-tan; 95 percent quartz, pebbles of sandstone and quartzite, some clayey tan silt in lower 10 feet | 15 | 115 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, yellowish-tan; quartzose, pebbles derived from Dakota Formation, some medium gravel in lower 5 feet | 10 | 125 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine gravel, yellowish-tan; many tan silt streaks | 5 | 130 |
![]() |
![]() |
![]() |
Clay, very silty, grayish-tan to gray; shale fragments present | 5 | 135 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, light-gray | 5 | 140 |
25-1W-18abb--Sample log of test hole 37T in NW NW NE sec. 18, T 25 S, R 1 W; drilled by the City of Wichita, February 1958. Altitude of land surface, 1,377.2 feet; depth to water, 19.6 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, dark-brown | 3 | 3 |
![]() |
![]() |
![]() |
Silt, very sandy, tan | 3 | 6 |
![]() |
![]() |
![]() |
Silt, clayey, sandy, grayish-tan | 8 | 14 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse arkosic gravel | 37 | 51 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Silt, sandy, grayish-tan | 2 | 53 |
![]() |
![]() |
![]() |
Sand, fine to coarse, grayish-white; quartzose | 14 | 67 |
![]() |
![]() |
![]() |
Silt, sandy, clayey, gray to tan; some caliche | 2 | 69 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; quartzose | 3 | 72 |
![]() |
![]() |
![]() |
Silt, clayey, sandy, grayish-tan; contains caliche | 2 | 74 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine gravel; quartzose | 5 | 79 |
![]() |
![]() |
![]() |
Silt, sandy, grayish-tan to tan | 6 | 85 |
![]() |
![]() |
![]() |
Silt, sandy, grayish-tan to pinkish-tan; contains streaks of sand | 12 | 97 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; grayish-white; quartzose, many streaks of tan sandy silt | 19 | 116 |
![]() |
![]() |
![]() |
Silt, sandy, clayey, tan, sand streak at 118 to 119 feet | 6 | 122 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel [Dakota(?)], yellowish-tan | 10 | 132 |
![]() |
![]() |
![]() |
Silt, clayey, sandy, tan; thin sand streaks | 11 | 143 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, yellowish-tan; quartzose | 8 | 151 |
![]() |
![]() |
![]() |
Silt, clayey, sandy, tan | 4 | 155 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, yellowish-tan; quartzose | 8 | 163 |
![]() |
![]() |
![]() |
Silt, clayey, sandy, tan | 1 | 164 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, yellowish-tan; quartzose | 3 | 167 |
![]() |
![]() |
![]() |
Silt, sandy, clayey, grayish-tan to yellowish-tan | 3 | 170 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, yellowish-tan; quartzose, contains material derived from Dakota Formation; thin clay streak at bottom | 6 | 176 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 4 | 180 |
25-1W-21daa--Driller's log of test hole in NE NE SE sec. 21, T 25 S, R 1 W; augered May 1955. Altitude of land surface, 1,360.2 feet; depth to water, 18.1 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Road fill | 3 | 3 |
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, tan | 9 | 12 |
![]() |
![]() |
![]() |
Silt, clayey, grayish-green; some organic material | 7 | 19 |
![]() |
![]() |
![]() |
Silt, clayey, gray and brown | 6 | 25 |
![]() |
![]() |
![]() |
Sand, fine to coarse, silty, gray; quartzose | 19 | 44 |
25-1W-22aaa--Sample log of test hole in NE NE NE sec. 22, T 25 S, R 1 W, on west side of road, 75 feet south of farm drive; augered September 1958. Altitude of land surface, 1,361 feet; depth to water, 12.9 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, dark-gray to brown | 5 | 5 |
![]() |
![]() |
![]() |
Silt, dark-tan | 5 | 10 |
![]() |
![]() |
![]() |
Silt, dark-tan; some fine sand | 5 | 15 |
![]() |
![]() |
![]() |
Silt, dark-tan; 18 to 20 feet is fine sand, silty | 5 | 20 |
![]() |
![]() |
![]() |
Sand, fine to medium, very silty | 5 | 25 |
![]() |
![]() |
![]() |
Sand, fine to coarse, silty | 5 | 30 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium silty gravel | 33 | 63 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 2 | 65 |
25-1W-22dcc--Driller's log of test hole in SW SW SE sec. 22, T 2.5 S, R 1 W; augered May 19.5.5. Altitude of land surface, 1,3.59 feet; depth to water, 8.5 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, black | 2 | 2 |
![]() |
![]() |
![]() |
Silt, brown | 1 | 3 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 6 | 9 |
![]() |
![]() |
![]() |
Silt, clayey, tan | 5 | 14 |
![]() |
![]() |
![]() |
Silt, clayey, sandy, gray | 5 | 19 |
![]() |
![]() |
![]() |
Silt, clayey, sandy, grayish-green | 5 | 24 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine gravel, silty, gray; some possible quartzitc present | 21 | 45 |
25-1W-23abb--Sample log of test hole in NW NW NE sec. 23, T 25 S, R 1 W; augered by the City of Wichita, 1959. Altitude of land surface, 1,360(T) feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, dark-gray | 5 | 5 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel, pinkish-gray; arkosic, much quartz; streaks of gray carbonaceous silt in lower 5 feet | 10 | 15 |
![]() |
![]() |
![]() |
Sand, fine to medium, silty | 5 | 20 |
![]() |
![]() |
![]() |
Silt, sandy, gray | 3 | 23 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel, grayish-pink; arkosic | 17 | 40 |
25-1W-25aaa--Sample log of test hole in NE NE NE sec. 25, T 25 S, R 1 W, on south side of road, 75 feet west of north-south road; augered September 1958. Altitude of land surface, 1,352.7 feet; depth to water, 14.5 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, clayey, dark-brown | 5 | 5 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 7 | 12 |
![]() |
![]() |
![]() |
Sand, fine | 1 | 13 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 2 | 15 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, very silty; arkosic | 10 | 25 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; arkosic, much quartz | 9 | 34 |
![]() |
![]() |
![]() |
Silt, sandy, gray | 1 | 35 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; some silt, more quartz in lower 7 feet | 12 | 47 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 1 | 48 |
25-1W-25cba--Sample log of test hole in NE NW SW sec. 25, T 25 S, R 1 W; augered by City of Wichita, July 1958. Altitude of land surface, 1,353.5 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Pleistocene Series, undifferentiated | ||||
![]() |
![]() |
![]() |
Clay, silty, black | 4 | 4 |
![]() |
![]() |
![]() |
Clay, silty, brown | 12 | 16 |
![]() |
![]() |
![]() |
Sand to coarse gravel, orangish-tan | 8 | 24 |
![]() |
![]() |
![]() |
Sand to fine gravel, tan | 8 | 32 |
![]() |
![]() |
![]() |
Clay, green | 1 | 33 |
![]() |
![]() |
![]() |
Sand, fine to coarse, gray | 6 | 39 |
![]() |
![]() |
![]() |
Sand and fine gravel, grayish-tan | 5 | 44 |
![]() |
![]() |
![]() |
Sand to medium gravel, grayish-tan | 8 | 52 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, yellowish-green | 1 | 53 |
25-1W-25ddc--Sample log of test hole in SW SE SE sec. 25, T 25 S, R 1 W; augered by City of Wichita, July 1958. Altitude of land surface, 1,324 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Soil | 3 | 3 |
![]() |
Pleistocene Series, undifferentiated | ||||
![]() |
![]() |
![]() |
Silt, tan to brown | 3 | 6 |
![]() |
![]() |
![]() |
Silt, tan, clayey | 3 | 9 |
![]() |
![]() |
![]() |
Silt and clay, tan | 8 | 17 |
![]() |
![]() |
![]() |
Sand, fine, yellowish-tan; dirty, coarser in lower 4 feet | 7 | 24 |
![]() |
![]() |
![]() |
Sand, fine to coarse, very silty, yellowish-tan | 10 | 34 |
![]() |
![]() |
![]() |
Sand, fine to medium, grayish-tan | 8 | 42 |
![]() |
![]() |
![]() |
Clay and sand, gray | 2 | 44 |
![]() |
![]() |
![]() |
Sand and fine gravel | 2 | 46 |
![]() |
![]() |
![]() |
Sand, gravel and clay layers | 3 | 49 |
![]() |
![]() |
![]() |
Sand to fine gravel, gray | 5 | 54 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, yellowish-green | 1 | 55 |
25-1W-26bbb--Driller's log of test hole in NW NW NW sec. 26, T 25 S, R 1 W, on the east edge of north-south road, even with center of road going west; augered July 1957. Altitude of land surface, 1,357.7 feet; depth to water, 21.5 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, brown | 2 | 2 |
![]() |
![]() |
![]() |
Silt, very sandy, tan | 2 | 4 |
![]() |
![]() |
![]() |
Sand, fine to medium | 5 | 9 |
![]() |
![]() |
![]() |
Silt | 3 | 12 |
![]() |
![]() |
![]() |
Sand, fine to coarse | 2 | 14 |
![]() |
![]() |
![]() |
Silt, clayey, gray | 8 | 22 |
![]() |
![]() |
![]() |
Sand, fine to medium, silty, some gravel | 2 | 24 |
![]() |
![]() |
![]() |
Sand, fine to medium, and fine to medium gravel, gray | 21 | 45 |
25-1W-26ccd--Driller's log of test hole in SE SW SW sec. 26, T 25 S, R 1 W; drilled by Layne-Western Co. for the Kansas Gas and Electric Co., July 1959. Altitude of land surface, 1,353(T) feet; depth to water, 14.0 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Pleistocene Series, undifferentiated | ||||
![]() |
![]() |
![]() |
Clay, brown | 3 | 3 |
![]() |
![]() |
![]() |
Sand, fine | 7 | 10 |
![]() |
![]() |
![]() |
Clay, gray | 7 | 17 |
![]() |
![]() |
![]() |
Sand and gravel | 47 | 64 |
![]() |
![]() |
![]() |
Clay, gray | 2 | 66 |
![]() |
![]() |
![]() |
Clay | 16 | 82 |
![]() |
![]() |
![]() |
Sand, fine to medium | 12 | 94 |
![]() |
![]() |
![]() |
Clay, brown | 2 | 96 |
![]() |
![]() |
![]() |
Sand, fine to medium | 8 | 104 |
![]() |
![]() |
![]() |
Clay and sand, brown | 2 | 106 |
![]() |
![]() |
![]() |
Sand, fine to medium | 8 | 114 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, clayey, green | 1 | 115 |
![]() |
![]() |
![]() |
Shale, blue | 10 | 125 |
25-1W-27ccc--Driller's log of test hole in SW SW SW sec. 27, T 25 S, R 1 W; drilled by Layne-Western Co. for the Kansas Gas and Electric Co., July B5.9. Altitude of land surface, 1,353 feet; depth to water, 10.8 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Pleistocene Series, undifferentiated | ||||
![]() |
![]() |
![]() |
Clay, brown | 8 | 8 |
![]() |
![]() |
![]() |
Sand, fine to medium | 7 | 15 |
![]() |
![]() |
![]() |
Sand and gravel, medium to coarse | 28 | 43 |
![]() |
![]() |
![]() |
Sand and gravel, medium to coarse, with some clay streaks | 8 | 51 |
![]() |
![]() |
![]() |
Sand and gravel, medium to coarse | 10 | 61 |
![]() |
![]() |
![]() |
Clay, sandy, brown | 3 | 64 |
![]() |
![]() |
![]() |
Sand, fine | 55 | 119 |
![]() |
![]() |
![]() |
Clay, sandy, brown | 3 | 122 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, blue | 8 | 130 |
25-1W-27daa--Driller's log of test hole in NE NE SE sec. 27, T 25 S, R 1 W; augered May 1955. Altitude of land surface, 1,356.1 feet; depth to water, 17.2 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, dark-gray | 2 | 2 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 4 | 6 |
![]() |
![]() |
![]() |
Sand, fine to medium | 6 | 12 |
![]() |
![]() |
![]() |
Silt, brown | 2 | 14 |
![]() |
![]() |
![]() |
Silt, dark-gray | 3 | 17 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, silty, gray | 7 | 24 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel, pink; arkosic | 25 | 49 |
25-1W-27ddd--Sample log of test hole in SE SE SE sec. 27, T 25 S, R 1 W; augered May 1955. Altitude of land surface, 1,357.6 feet; depth to water, 16.0 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Soil | 2 | 2 |
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Sand, fine to coarse, very silty, tan | 2 | 4 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic | 15 | 19 |
![]() |
![]() |
![]() |
Silt, sandy, dark grayish-brown; some fine to medium gravel and caliche | 5 | 24 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel, silty; arkosic, much quartz | 15 | 39 |
25-1W-8ada--Driller's log of test hole in NE SE NE sec. 28, T 25 S, R 1 W; drilled by Layne-Western Co. for the Kansas Gas and Electric Co., July 1959. Altitude of land surface, 1,362(T) feet; depth to water, 15.8 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Soil | 3 | 3 |
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Sand, medium and coarse, and gravel | 13 | 16 |
![]() |
![]() |
![]() |
Clay, gray | 3 | 19 |
![]() |
![]() |
![]() |
Sand, medium and coarse, and gravel | 26 | 45 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, blue | 122 |
25-1W-28cdd--Sample log of test hole in SE SE SW sec, 28, T 25 S, R 1 W; drilled by Layne-Western Co. for the Kansas Gas and Electric Co., July 1959. Altitude of land surface, 1,357 feet; depth to water, 12.0 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Pleistocene Series, undifferentiated | ||||
![]() |
![]() |
![]() |
Clay, brown | 4 | 4 |
![]() |
![]() |
![]() |
Sand, medium to coarse; gravel in lower 10 feet | 31 | 35 |
![]() |
![]() |
![]() |
Clay, brown | 2 | 37 |
![]() |
![]() |
![]() |
Sand, medium to coarse, and gravel; abundant clay in lower 8 feet | 16 | 53 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and gravel | 7 | 60 |
![]() |
![]() |
![]() |
Sand, fine to medium | 27 | 87 |
![]() |
![]() |
![]() |
Clay, brown | 2 | 89 |
![]() |
![]() |
![]() |
Sand, fine to medium | 14 | 103 |
![]() |
![]() |
![]() |
Clay, sandy, brown | 9 | 112 |
![]() |
![]() |
![]() |
Sand, fine to medium | 7 | 119 |
![]() |
![]() |
![]() |
Clay, sandy, gray | 3 | 122 |
![]() |
![]() |
![]() |
Sand, fine; layer of clay | 6 | 128 |
![]() |
![]() |
![]() |
Sand, fine to coarse | 6 | 134 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale | 6 | 140 |
25-1W-32ccc--Sample log of test hole in SW SW SW sec. 32, T 25 S, R 1 W, in road, 200 feet northwest of curve, 15 feet from fence; drilled September 1958. Altitude of land surface, 1,362.8 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, grayish-brown; contains caliche | 5 | 5 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; arkosic; streaks of grayish-tan silt in lower 5 feet | 15 | 20 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic; some coarse gravel in lower 10 feet | 15 | 35 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; some tan silt and lower 15 feet has streaks of tan clay | 20 | 55 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Clay, silty, gray to tan | 2 | 57 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel | 2 | 59 |
![]() |
![]() |
![]() |
Clay, silty, gray and tan | 3 | 62 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; quartzose and arkosic, some clay streaks | 3 | 65 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; 90 percent quartz, streaks of gray clay | 10 | 75 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, clayey, silty, gray to tan | 5 | 80 |
![]() |
![]() |
![]() |
Sand, fine to coarse and some fine gravel; streaks of grayish-tan, clayey silt; lower 5 feet has very little gravel | 10 | 90 |
![]() |
![]() |
![]() |
Silt, clayey, gray to tan; streaks of sand and gravel; some arkosic | 10 | 100 |
![]() |
![]() |
![]() |
Silt, tan; arkosic sand streaks and caliche pebbles | 10 | 110 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; many streaks of tan silt and gray clay | 5 | 115 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, slightly silty; 95 percent quartz | 5 | 120 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; streaks of grayish-tan clayey silt | 10 | 130 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, 95 percent quartz, some tan clayey silt | 5 | 135 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; quartzose | 15 | 150 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; quartzose, thin streaks of gray clay | 10 | 160 |
![]() |
![]() |
![]() |
Silt, contains sand and fine to medium gravel; some dark gravel present | 8 | 168 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 2 | 170 |
25-1W-34daa--Driller's log of test hole in NE NE SE sec. 34, T 25 S, R 1 W; augered May 1955. Altitude of land surface, 1,352.3 feet; depth to water, 14.5 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, dark-gray | 2 | 2 |
![]() |
![]() |
![]() |
Silt, tan | 2 | 4 |
![]() |
![]() |
![]() |
Sand, fine to coarse, some gravel; arkosic | 10 | 14 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel, pink; arkosic | 31 | 45 |
25-1W-34ddd--Sample log of test hole in SE SE SE sec. 34, T 25 S, R 1 W; augered May 1955. Altitude of land surface, 1,350.95 feet; depth to water, 11.8 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, dark-gray | 3 | 3 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 1 | 4 |
![]() |
![]() |
![]() |
Sand, fine to coarse | 5 | 9 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; arkosic | 35 | 44 |
25-1W-35cbb--Driller's log of test hole in NW NW SW sec. 35. T 25 S, R 1 W; drilled by Layne-Western Co. for the Kansas Gas and Electric Co., July 1959. Altitude of land surface, 1,351 feet; depth to water, 12.3 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Soil | 1 | 1 |
![]() |
Pleistocene Series, undifferentiated | ||||
![]() |
![]() |
![]() |
Clay, grayish-brown | 5 | 6 |
![]() |
![]() |
![]() |
Sand, fine to medium | 4 | 10 |
![]() |
![]() |
![]() |
Sand, medium to coarse; some gravel | 53 | 63 |
![]() |
![]() |
![]() |
Sand, medium, and clay | 22 | 85 |
![]() |
![]() |
![]() |
Sand, fine to medium; clay balls | 28 | 113 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale | 7 | 120 |
25-1W-35daa--Driller's log of test hole in NE NE SE sec. 35, T 25 S, R 1 W; drilled by Layne-Western Co. for the Kansas Gas and Electric Co., July 1959. Altitude of land surface, 1,342 feet; depth to water 13.0 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Soil | 2 | 2 |
![]() |
Pleistocene Series, undifferentiated | ||||
![]() |
![]() |
![]() |
Clay, brown; sandy in lower 4 feet | 10 | 12 |
![]() |
![]() |
![]() |
Sand, fine to medium | 3 | 15 |
![]() |
![]() |
![]() |
Sand, medium to coarse, and gravel; some clay in lower 15 feet | 43 | 58 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, blue and gray | 12 | 70 |
25-1W-35dcc--Sample log of test hole in SW SW SE sec. 35, T 25 S, R 1 W; augered May 1955. Altitude of land surface, 1,347.0 feet; depth to water, 10.2 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, dark-gray | 2 | 2 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 1 | 3 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and some fine to medium gravel; arkosic | 20 | 23 |
![]() |
![]() |
![]() |
Silt, clayey, gray | 2 | 25 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel, silty; arkosic, much quartz | 19 | 44 |
25-1W-35ddd--Driller's log of test hole in SE SE SE sec. 35, T 25 S, R 1 W; augered May 1955. Altitude of land surface, 1,345.5 feet; depth to water, 14.9 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, tan | 2 | 2 |
![]() |
![]() |
![]() |
Sand, fine to medium | 2 | 4 |
![]() |
![]() |
![]() |
Silt, brown; contains caliche | 2 | 6 |
![]() |
![]() |
![]() |
Silt, sandy, dark-gray | 2 | 8 |
![]() |
![]() |
![]() |
Sand, fine to medium | 5 | 13 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel, pink; arkosic | 36 | 49 |
25-2W-2aaa--Driller's log of test hole in NE NE NE sec. 2, T 25 S, R 2 W, (Williams and Lohman, 1949, p. 425) drilled by the City of Wichita, 1938. Altitude of land surface, 1,389 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Soil | 5 | 5 |
![]() |
Pleistocene Series, undifferentiated | ||||
![]() |
![]() |
![]() |
Sand, coarse | 15 | 20 |
![]() |
![]() |
![]() |
Sand and clay | 15 | 35 |
![]() |
![]() |
![]() |
Sand, fine | 5 | 40 |
![]() |
![]() |
![]() |
Gravel | 10 | 50 |
![]() |
![]() |
![]() |
Clay, and gravel | 15 | 65 |
![]() |
![]() |
![]() |
Gravel | 20 | 85 |
![]() |
![]() |
![]() |
Sand, coarse | 5 | 90 |
![]() |
![]() |
![]() |
Clay and gravel | 10 | 100 |
![]() |
![]() |
![]() |
Clay | 60 | 160 |
![]() |
![]() |
![]() |
Sand and clay | 25 | 185 |
![]() |
![]() |
![]() |
Sand, fine | 10 | 195 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale | 4 | 199 |
25-2W-2bbb--Sample log of test hole in NW NW NW sec. 2, T 25 S, R 2 W; drilled by Layne-Western Co. for the City of Wichita, 1947. Altitude of land surface, 1,393.3 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, light-gray to tan | 17 | 17 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel, grayish-pink; arkosic, streaks of grayish-tan sandy silt in lower 5 feet | 11 | 28 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel, grayish-pink; arkosic, streaks of gray to grayish-brown sandy silt in lower 5 feet | 22 | 50 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, grayish-pink; arkosic, much quartz | 5 | 55 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, gray; quartzose | 5 | 60 |
![]() |
![]() |
![]() |
Sand, fine to coarse, tannish-gray; quartzose, some arkosic; with streaks of grayish-tan sandy silt in lower 10 feet | 30 | 90 |
![]() |
![]() |
![]() |
Sand, fine to coarse, silty, tannish-gray; contains caliche and snails | 10 | 100 |
![]() |
![]() |
![]() |
Silt, very sandy, tan to light-gray; caliche in lower 15 feet | 20 | 120 |
![]() |
![]() |
![]() |
Silt, light-gray; streaks of fine to coarse sand; arkose, snails present | 10 | 130 |
![]() |
![]() |
![]() |
Silt, light-gray; streaks of fine to coarse sand, quartzose | 3 | 133 |
![]() |
![]() |
![]() |
Sand, fine to coarse; quartzose; many streaks of gray sandy silt; some snails | 10 | 143 |
![]() |
![]() |
![]() |
Sand, fine to coarse, gray; quartzose, caliche pebbles in lower 10 feet | 17 | 160 |
![]() |
![]() |
![]() |
Sand, fine to coarse; gray, sandy silt streaks and caliche pebbles; snails in lower 20 feet, vertebrate fragments in lower 10 feet | 35 | 195 |
![]() |
![]() |
![]() |
Silt, very sandy, gray to grayish-tan | 5 | 200 |
![]() |
![]() |
![]() |
Sand, fine to coarse; quartzose, with caliche pebbles | 15 | 215 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 5 | 220 |
25-2W-3add--Driller's log of test hole in SE SE NE sec. 3, T 25 S, R 2 W; augered by the City of Wichita, July 1954. Altitude of land surface, 1,393.9 feet; depth to water, 24.0 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Topsoil | 1 | 1 |
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Sand and fine sand, tan | 1 | 2 |
![]() |
![]() |
![]() |
Sand, fine to medium, silty | 5 | 7 |
![]() |
![]() |
![]() |
Sand, fine to coarse, tan; clean | 3 | 10 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine to medium gravel | 5 | 15 |
![]() |
![]() |
![]() |
Sand, fine to medium, tan; fine gravel in lower 10 feet, clean | 15 | 30 |
![]() |
![]() |
![]() |
Sand, medium to coarse, and fine to coarse gravel; clean | 15 | 45 |
![]() |
![]() |
![]() |
Silt, clayey, dark bluish-gray; tough | 4 | 49 |
![]() |
![]() |
![]() |
Sand, fine to coarse, tan | 11 | 60 |
25-2W-3ccc--Driller's log of test hole in SW SW SW sec. 3, T 25 S, R 2 W; augered by the City of Wichita, July 1954. Altitude of land surface, 1,395.9 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Topsoil, sandy, brown | 1 | 1 |
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, and fine sand, light-brown | 5 | 6 |
![]() |
![]() |
![]() |
Sand, fine, tan | 2 | 8 |
![]() |
![]() |
![]() |
Sand, fine to medium, tan; coarser sand in lower 3 feet | 6 | 14 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel | 38 | 52 |
![]() |
![]() |
![]() |
Clay, light-gray; soft | 3 | 55 |
25-2W-3ddd--Driller's log of test hole in SE SE SE sec. 3, T 25 S, R 2 W, 700 feet northwest of City well no. 29; augered by the City of Wichita. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Sand, fine to medium, brown | 2 | 2 |
![]() |
![]() |
![]() |
Sand, silty, tannish-brown | 8 | 10 |
![]() |
![]() |
![]() |
Sand, fine to medium, tan; clean | 6 | 16 |
![]() |
![]() |
![]() |
Sand, fine to medium, silty, brown | 1 | 17 |
![]() |
![]() |
![]() |
Sand, fine to medium, gray | 10 | 27 |
![]() |
![]() |
![]() |
Sand, fine to coarse, grayish-tan; clean | 10 | 37 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, grayish-tan; clean | 8 | 45 |
![]() |
![]() |
![]() |
Clay, yellowish-brown; tough | 5 | 50 |
25-2W-4ccc--Sample log of test hole in SW SW SW sec. 4, T 25 S, R 2 W; drilled by City of Wichita, February 1958. Altitude of land surface, 1,400.0 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, dark-brown | 2 | 2 |
![]() |
![]() |
![]() |
Sand, fine to coarse | 2 | 4 |
![]() |
![]() |
![]() |
Silt, sandy, clayey, grayish-tan | 2 | 6 |
![]() |
![]() |
![]() |
Sand, fine to coarse and fine to coarse gravel; arkosic with some clark gravel | 9 | 15 |
![]() |
![]() |
![]() |
Silt, dark-gray; streak of sand and gravel from 16 to 17 feet | 3 | 18 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; arkosic | 31 | 49 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Silt, sandy, tan to gray | 6 | 55 |
![]() |
![]() |
![]() |
Sand | 2 | 57 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 19 | 76 |
![]() |
![]() |
![]() |
Silt, sandy, grayish-tan; much caliche | 6 | 82 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; arkosic | 9 | 91 |
![]() |
![]() |
![]() |
Silt | 1 | 92 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; arkosic | 4 | 96 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 4 | 100 |
![]() |
![]() |
![]() |
Sand, fine to coarse | 1 | 101 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 2 | 103 |
![]() |
![]() |
![]() |
Sand, fine to coarse | 2 | 105 |
![]() |
![]() |
![]() |
Silt, very sandy, light-gray | 5 | 110 |
![]() |
![]() |
![]() |
Sand, fine to coarse | 2 | 112 |
![]() |
![]() |
![]() |
Silt, sandy, pinkish-tan | 6 | 118 |
![]() |
![]() |
![]() |
Sand | 2 | 120 |
![]() |
![]() |
![]() |
Silt, sandy, pinkish-tan | 3 | 123 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; arkosic | 19 | 142 |
![]() |
![]() |
![]() |
Silt, sandy, clayey, tan; sand streaks at 144, 150, and 155 feet | 15 | 157 |
![]() |
![]() |
![]() |
Sand, fine to coarse; quartzose | 6 | 163 |
![]() |
![]() |
![]() |
Silt, sandy; light-gray sand, sand streaks at 164 and 169 feet | 17 | 180 |
![]() |
![]() |
![]() |
Silt, sandy, yellowish-tan | 10 | 190 |
![]() |
![]() |
![]() |
Silt, sandy, light-tan; carbonaceous specks | 13 | 203 |
![]() |
![]() |
![]() |
Silt, fine to coarse, and fine gravel; quartzose, many streaks of tan silt | 11 | 214 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, light-gray | 4 | 218 |
25-2W-5bbb--Sample log of test; hole 51T in NW NW NW sec. 5, T 25 S, R 2 W, 240 feet west of City well M51; drilled by Layne-Western Co. for the City of Wichita, January 1958. Altitude of land surface, 1,409.3 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, very sandy, tan | 4 | 4 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic | 8 | 12 |
![]() |
![]() |
![]() |
Silt, sandy, gray | 2 | 14 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel, pinkish-gray; arkosic, very weathered | 36 | 50 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Silt, very sandy, clayey, reddish-tan; some caliche in lower 10 feet | 30 | 80 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, tan; arkosic; few streaks of sandy tan silt in lower 15 feet | 25 | 105 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, tan; arkosic | 5 | 110 |
![]() |
![]() |
![]() |
Silt, sandy gray to tan; carbonaceous specks in the gray silt | 5 | 115 |
![]() |
![]() |
![]() |
Silt, very sandy, tan; some caliche; clayey in lower 10 feet | 15 | 130 |
![]() |
![]() |
![]() |
Silt, very sandy, tan; clayey with a few sand streaks in lower 10 feet | 20 | 150 |
![]() |
![]() |
![]() |
Sand, fine to coarse; quartzose with many silt streaks | 5 | 155 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, yellowish-gray; predominantly quartz, gravel is of the Dakota type; silt streaks with carbonaceous specks | 30 | 185 |
![]() |
![]() |
![]() |
Silt, sandy, very calcareous, light-gray; sand streaks in lower 5 feet | 10 | 195 |
![]() |
![]() |
![]() |
Sand, fine to coarse, silty, yellowish-gray; Dakota type | 7 | 202 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 4 | 206 |
25-2W-5bcc--Sample log of test hole 52T in SW SW NW sec. 5, T 25 S, R 2 W, 240 feet southwest of City well M52; drilled by Layne-Western Co. for the City of Wichita, January 1958. Altitude of land surface, 1,407.9 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, dark-gray to tan | 4 | 4 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic; coarse gravel in lower 25 feet | 36 | 40 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic; some sandy tan silt | 15 | 55 |
![]() |
![]() |
Pliocene(?) and Pleistocene Series, undifferentiated | |||
![]() |
![]() |
![]() |
Silt, very sandy, tan | 13 | 68 |
![]() |
![]() |
![]() |
Sand, fine to medium | 2 | 70 |
![]() |
![]() |
![]() |
Silt, very sandy, tan | 10 | 80 |
![]() |
![]() |
![]() |
Silt, sandy, grayish-tan; some caliche | 5 | 85 |
![]() |
![]() |
![]() |
Sand, fine to coarse; predominantly quartz | 3 | 88 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 4 | 92 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; predominantly quartz with some arkose | 7 | 99 |
![]() |
![]() |
![]() |
Silt, very sandy, grayish-tan | 6 | 105 |
![]() |
![]() |
![]() |
Sand, fine to coarse, tan; arkosic | 14 | 119 |
![]() |
![]() |
![]() |
Silt, very sandy, grayish-tan to tan | 10 | 129 |
![]() |
![]() |
![]() |
Sand, fine to medium; predominantly quartz | 6 | 135 |
![]() |
![]() |
![]() |
Silt, very sandy, some gravel, grayish-tan | 20 | 155 |
![]() |
![]() |
![]() |
Silt, sandy, gray to tan; includes many fragments of Wellington shale | 5 | 160 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale | 25 | 185 |
25-2W-5ccd--Sample log of test hole 53T in SE SW SW sec. 5, T 25 S, R 2 W, 240 feet southwest of City well no. M53; drilled by Layne-Western Co. for the City of Wichita, January 1958. Altitude of land surface, 1,405.5 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, tan | 5 | 5 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; arkosic | 35 | 40 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Silt, sandy, tan; some sand streaks | 5 | 45 |
![]() |
![]() |
![]() |
Silt, sandy, clayey, tan to grayish-tan; very sandy at base | 10 | 55 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic with streaks of tan sandy silt | 17 | 72 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 5 | 77 |
![]() |
![]() |
![]() |
Sand, fine to medium, grayish-tan; predominantly quartz, some arkosic | 13 | 90 |
![]() |
![]() |
![]() |
Silt, sandy, to clayey, tan to dark-tan; contains carbonaceous material in lower 15 feet | 30 | 120 |
![]() |
![]() |
![]() |
Silt, sandy, tan to reddish-brown; contains fragments of Permian red beds | 5 | 125 |
![]() |
![]() |
![]() |
Silt, tan, reddish-brown and grayish-green; contains Permian rubble | 5 | 130 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray to grayish-green, hard; with thin beds of hard limestone | 20 | 150 |
25-2W-5dbb--Sample log of City well M54 in NW NW SE sec. 5, T 25 S, R 2 W; drilled by Layne-Western Co. for the City of Wichita, February 1958. Altitude of land surface, 1,404.8 feet; depth to water, 7.7 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
![]() |
![]() |
![]() |
Soil | 1 | 1 |
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, grayish-tan; some caliche | 4 | 5 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic; coarser gravel in lower 40 feet | 45 | 50 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Silt, sandy, tan; some caliche; clayey in lower 5 feet | 10 | 60 |
![]() |
![]() |
![]() |
Silt, sandy, grayish-tan; contains some caliche pebbles | 5 | 65 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; arkosic; few grayish-tan silt streaks | 5 | 70 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; arkosic; finer gravel in lower 10 feet, grayish-tan silty clay at base | 15 | 85 |
25-2W-6ddd--Sample log of test hole 3T in SE SE SE sec. 6, T 25 S, R 2 W; drilled by the City of Wichita, January 1956. Altitude of land surface, 1,405(T) feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Soil | 2 | 2 |
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, tan | 4 | 6 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; arkosic | 47 | 53 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Silt, very sandy, tan | 3 | 56 |
![]() |
![]() |
![]() |
Sand, fine | 2 | 58 |
![]() |
![]() |
![]() |
Silt, sandy, grayish-tan to tan | 9 | 67 |
![]() |
![]() |
![]() |
Sand, fine | 2 | 69 |
![]() |
![]() |
![]() |
Silt, sandy, light-gray to tan; some caliche | 7 | 76 |
![]() |
![]() |
![]() |
Sand, fine; some silt | 5 | 81 |
![]() |
![]() |
![]() |
Silt, very sandy, grayish-tan; some caliche and specks of carbon | 15 | 96 |
![]() |
![]() |
![]() |
Silt and sand streaks | 2 | 98 |
![]() |
![]() |
![]() |
Sand, fine to medium, tan; arkosic | 14 | 112 |
![]() |
![]() |
![]() |
Silt, very sandy, tan | 21 | 133 |
![]() |
![]() |
![]() |
Silt, sandy, tannish-gray; much red and gray shale fragments and caliche pebbles | 10 | 143 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, light-gray to dark-gray; some thin limestone streaks | 15 | 158 |
25-2W-9aaa--Sample log of test hole in NE NE NE sec. 9, T 25 S, R 2 W; drilled by the City of Wichita, 1938. Altitude of land surface, 1,395.6 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, very sandy, brown to tan; contains caliche | 4 | 4 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; arkosic; sandy gray silt streak at 26 to 27 feet | 27 | 31 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; arkosic; streaks of sandy tan silt and clay in lower 3 feet | 11 | 42 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Sand, fine to medium; predominantly quartz, many tan sandy silt streaks | 12 | 54 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic | 6 | 60 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 1 | 61 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic; streaks of sandy, clayey tan silt | 12 | 73 |
![]() |
![]() |
![]() |
Silt, clayey, sandy, light tannish-gray; calcareous; thin streaks of sand and fine gravel | 40 | 113 |
![]() |
![]() |
![]() |
Silt, very sandy, light-tan; calcareous | 8 | 121 |
![]() |
![]() |
![]() |
Sand, fine to coarse, silty; quartz | 4 | 125 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, tannish-gray; quartzose | 6 | 131 |
![]() |
![]() |
![]() |
Sand, fine to coarse; quartz; streaks of grayish-tan silt with caliche | 7 | 138 |
![]() |
![]() |
![]() |
Sand, fine to coarse; quartzose | 3 | 141 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 2 | 143 |
![]() |
![]() |
![]() |
Sand, fine to coarse, gray; quartzose; with streaks of tannish-gray clay with caliche | 11 | 154 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; quartzose | 5 | 159 |
![]() |
![]() |
![]() |
Silt, very sandy, light grayish-tan; some caliche | 8 | 167 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; quartzose; abundant shale fragments and tan silt, clay with caliche pebbles | 13 | 180 |
![]() |
![]() |
![]() |
Silt, sandy, light grayish-tan; calcareous with some caliche | 17 | 197 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; quartzose, some silt, caliche, and shale fragments in lower 4 feet | 16 | 213 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, very silty; quartzose, and some caliche | 10 | 223 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; quartzose, abundant caliche pebbles and shale fragments | 5 | 228 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 7 | 235 |
25-2W-11baa--Sample log of test hole 30T in NE NE NW sec 11, T 25 S, R 2 W; drilled by Layne-Western Co. for the City of Wichita, 1947. Altitude of land surface, 1,389.0 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, very sandy, dark-gray | 3 | 3 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic, streaks of sandy tan to gray silt; coarser gravel in lower 10 feet | 22 | 25 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; arkosic | 20 | 45 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Sand, fine to coarse and fine gravel; arkosic; many clayey, sandy, gray to grayish-tan silt streaks and some caliche and quartz in lower 10 feet | 25 | 70 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; arkosic | 10 | 80 |
![]() |
![]() |
![]() |
Sand, fine to coarse; quartzose with streaks of sandy, clayey, medium-gray to tan silt; caliche pebbles in lower 25 feet | 35 | 115 |
![]() |
![]() |
![]() |
Silt, very sandy, light-gray to tannish-gray; some caliche pebbles; snail fragments in lower 27 feet | 42 | 157 |
![]() |
![]() |
![]() |
Sand, fine to medium; quartzose, much arkose | 5 | 162 |
![]() |
![]() |
![]() |
Silt, very sandy, tannish-gray; many sand streaks | 8 | 170 |
![]() |
![]() |
![]() |
Sand, fine to coarse; predominantly quartz, some arkose; some fine gravel 178 to 185 feet and 200 to 227 feet; grayish-tan silt streaks scattered throughout with some caliche pebbles in lower 17 feet | 57 | 227 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale | 3 | 230 |
25-2W-11bbb--Sample log of test hole 29T in NW NW NW sec. 11, T 25 S, R 2 W; drilled by Layne-Western Co. for the City of Wichita, 1947. Altitude of land surface, 1,392. 7 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, light-gray to tan; some caliche | 20 | 20 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; arkosic; some sandy, clayey, grayish-tan silt | 20 | 20 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Silt, sandy, very clayey, light-gray to grayish-tan; some caliche | 6 | 46 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; arkosic, much quartz; thin streaks of silty tan clay in lower 10 feet | 14 | 60 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic, abundant quartz, coarser gravel in lower 5 feet | 10 | 70 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic with streaks of tan sandy silt | 5 | 75 |
![]() |
![]() |
![]() |
Silt, sandy, clayey, tan to dark-gray; snails and caliche present in lower 10 feet | 15 | 90 |
![]() |
![]() |
![]() |
Sand, fine to coarse, gray; quartzose, some caliche pebbles and gray to grayish-tan silt streaks | 30 | 120 |
![]() |
![]() |
![]() |
Silt, clayey, very sandy, light-gray to grayish-tan; abundant caliche; lower 5 feet darker gray | 25 | 145 |
![]() |
![]() |
![]() |
Sand, fine to coarse; quartzose with abundant arkose, clayey, gray silt streaks | 10 | 155 |
![]() |
![]() |
![]() |
Sand, fine to medium; quartzose with abundant arkose, some sandy grayish-tan silt; coarser sand in lower 10 feet | 20 | 175 |
![]() |
![]() |
![]() |
Sand, fine to coarse, gray; quartzose, contains some very sandy grayish-tan silt and caliche; lower 20 feet has gray shale fragments | 50 | 225 |
![]() |
![]() |
![]() |
Silt, sandy, gray; contains caliche pebbles and shale fragments, streaks of fine to coarse gray sand | 7 | 232 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 8 | 240 |
25-2W-12baa--Sample log of test hole 32T in NE NE NW sec. 12, T 25 S, R 2 W; drilled by Layne-Western Co. for the City of Wichita, 1947. Altitude of land surface 1,385.4 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, grayish-tan to dark-gray; some caliche and carbonaceous specks | 15 | 15 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; arkosic | 20 | 35 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; predominantly quartz | 35 | 70 |
![]() |
![]() |
![]() |
Sand, fine to coarse, predominantly quartz | 10 | 80 |
![]() |
![]() |
![]() |
Silt, sandy, grayish-tan; abundant sand streaks and caliche pebbles | 15 | 95 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; quartzose with some arkose; tan and gray silt streaks and caliche in lower 5 feet | 15 | 110 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; predominantly quartz with some clayey, sandy tan silt | 10 | 120 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; predominantly quartz with some arkose, with clayey, sandy, grayish-tan silt in lower 5 feet | 15 | 135 |
![]() |
![]() |
![]() |
Silt, clayey, very sandy, grayish-tan; some caliche | 12 | 147 |
![]() |
![]() |
![]() |
Sand, fine to coarse; predominantly quartz, streaks of sandy tan to grayish-tan silt; some fine gravel in the lower 20 feet | 28 | 175 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; predominantly quartz; some silt streaks in lower 5 feet | 10 | 185 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 5 | 190 |
25-2W-12bbb--Sample log of test hole 31T in NW NW NW sec. 12, T 25 S, R 2 W; drilled by Layne-Western Co. for the City of Wichita. Altitude of land surface, 1,388 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, gray to tan; some caliche | 8 | 8 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; arkosic | 2 | 10 |
![]() |
![]() |
![]() |
Silt, sandy, medium-gray | 6 | 16 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; grayish-pink; arkosic, much sandy, gray silt in upper 5 feet and lower 5 feet; abundant gray feldspar in lower 40 feet | 44 | 60 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; predominantly quartz, some arkose | 10 | 70 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; abundant white and gray feldspar, arkosic | 10 | 80 |
![]() |
![]() |
![]() |
Sand, fine to coarse, gray; quartzose; some fine gravel, caliche and gray silt streaks in lower 10 feet | 20 | 100 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; quartzose, with caliche and streaks of sandy gray silt | 10 | 110 |
![]() |
![]() |
![]() |
Sand, fine to coarse, predominantly fine to medium; quartz; some silt with caliche | 15 | 125 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; quartzose with some arkose, much sandy gray to grayish-tan silt; no gravel in lower 25 feet | 45 | 170 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel, grayish-pink; predominantly quartz with much arkosic material; streaks of sandy grayish-brown silt in lower 5 feet | 15 | 185 |
![]() |
![]() |
![]() |
Sand, fine to coarse; quartzose, very little arkose | 10 | 195 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 5 | 200 |
25-2W-16bbb--Sample log of test hole in NW NW NW sec. 16, T 25 S, R 2 W; drilled for the City of Wichita, 1938. Altitude of land surface, 1,397.0 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, grayish-brown to dark-tan | 4 | 4 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; arkosic, much black-stained gravel in lower 16 feet | 25 | 29 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; silty clay streaks in upper 2 feet with arkose in lower 5 feet | 7 | 36 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic with a few streaks of silty tan clay | 18 | 54 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; arkosic with tan sandy silt streaks near base | 23 | 90 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Silt, very sandy, light-tan | 8 | 67 |
![]() |
![]() |
![]() |
Sand, fine to medium; quartz, much sandy tan silt; some caliche near base | 23 | 90 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic, much sandy tan silt | 12 | 102 |
![]() |
![]() |
![]() |
Sand, fine to medium, some coarse; much sandy tan silt | 9 | 111 |
![]() |
![]() |
![]() |
Silt, very sandy, light grayish-tan; some caliche at 128 feet and at base | 50 | 161 |
![]() |
![]() |
![]() |
Silt, very sandy, tan; some caliche nodules | 7 | 168 |
![]() |
![]() |
![]() |
Silt, sandy, grayish-tan; many caliche nodules and fragments of gray and green shale | 26 | 194 |
![]() |
![]() |
![]() |
Sand, fine to medium; much sandy grayish-tan silt | 7 | 201 |
![]() |
![]() |
![]() |
Silt, clayey, sandy, light-gray; caliche pebbles and shale fragments | 2 | 203 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray; some thin limestone beds | 7 | 210 |
25-2W-16ccc--Sample log of test hole in SW SW SW sec. 16, T 25 8, R 2 W; drilled for the City of Wichita, 1938. Altitude of land surface, 1,391.3 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, sandy, grayish-brown to tan | 6 | 6 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; arkosic, no coarse gravel in lower 14 to 24 feet | 29 | 35 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Silt, sandy, tan to light grayish-tan | 11 | 46 |
![]() |
![]() |
![]() |
Silt, very sandy, tan to light-gray | 14 | 60 |
![]() |
![]() |
![]() |
Sand, fine to medium; quartzose, much light-gray silt | 10 | 70 |
![]() |
![]() |
![]() |
Sand, fine to medium; predominantly quartz, some arkosic; much sandy grayish-tan silt | 7 | 77 |
![]() |
![]() |
![]() |
Silt, light-tan; contains much fine to medium sand | 17 | 94 |
![]() |
![]() |
![]() |
Sand, fine to medium; quartzose, some sandy, light grayish-tan silt | 10 | 104 |
![]() |
![]() |
![]() |
Silt, very sandy, light-tan too tan | 12 | 116 |
![]() |
![]() |
![]() |
Silt, fine to medium, much tan sandy silt | 14 | 130 |
![]() |
![]() |
![]() |
Silt, very sandy, tan; much fine to medium sand and carbonaceous material; clayey, with caliche in lower 5 feet | 14 | 144 |
![]() |
![]() |
![]() |
Silt, sandy, clayey, light-gray to grayish-tan; calcareous | 8 | 152 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, light-gray | 152 |
25-2W-24ccc--Driller's log of test hole in SW SW SW sec. 24, T 25 S, R 2 W (Williams and Lohman, 1949, p. 430); drilled 1941. Altitude of land surface, 1,378 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Pleistocene Series, undifferentiated | ||||
![]() |
![]() |
![]() |
Silt | 12 12 | |
![]() |
![]() |
![]() |
Sand and gravel | 16 | 28 |
![]() |
![]() |
![]() |
Silt and clay | 5 | 33 |
![]() |
![]() |
![]() |
Sand | 27 | 60 |
![]() |
![]() |
![]() |
Silt and clay | 5 | 65 |
![]() |
![]() |
![]() |
Sand | 5 | 70 |
![]() |
![]() |
![]() |
Silt and clay | 2 | 72 |
![]() |
![]() |
![]() |
Sand and gravel | 93 | 165 |
![]() |
![]() |
![]() |
Silt and clay | 7 | 172 |
![]() |
![]() |
![]() |
Sand | 28 | 200 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale | 1 | 201 |
25-2W-29bbb--Sample log of test hole in NW cor. sec. 29, T 25 S, R 2 W (Williams and Lohman, 1949, p. 431); drilled 1939. Altitude of land surface, 1,393.4 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Soil | 3 | 3 |
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt and clay, brown, sandy | 4 | 7 |
![]() |
![]() |
![]() |
Gravel, coarse; contains clay balls | 38 | 45 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Silt and clay, tan; contains sand | 25 | 70 |
![]() |
![]() |
![]() |
Gravel, coarse | 53 | 123 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 7 | 130 |
25-2W-31bbb--Sample log of test hole in NW NW NW sec. 31, T 25 S, R 2 W; drilled 1939. Altitude of land surface, 1,417.2 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Illinoisan Stage (terrace deposits) | |||
![]() |
![]() |
![]() |
Silt, sandy, tan to brown, some light grayish-tan in lower 11 feet | 36 | 36 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel, grayish-pink; arkosic, with abundant quartz; coarse gravel 51 to 60 feet, finer gravel 60 to 69 feet; some clayey, gray to tan silt from 45 to 51 feet | 33 | 69 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel, grayish-pink; arkosic; fine gravel in lower 5 feet | 16 | 85 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Silt, sandy, clayey, grayish-tan | 1 | 86 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel, grayish-pink; arkosic; coarse gravel 90 to 100 feet and 104 to 118 feet; fine gravel with streaks of sandy gray silt 100 to 104 feet | 32 | 118 |
![]() |
![]() |
![]() |
Sand, fine to coarse; arkosic, with sandy gray to tan silt; fine to medium gravel in lower 10 feet | 12 | 130 |
![]() |
![]() |
![]() |
Silt, sandy, light tannish-gray | 5 | 135 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; arkosic | 10 | 145 |
![]() |
![]() |
![]() |
Silt, sandy, tan | 5 | 150 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; arkosic | 15 | 165 |
Permian | |||||
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; arkosic; no coarse gravel in lower 7 feet, streaks of clayey tan silt with caliche in lower 2 feet | 12 | 177 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic, much sandy tan silt, fine gravel, and less silt in lower 8 feet | 16 | 193 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; arkosic | 8 | 201 |
![]() |
![]() |
![]() |
Sand, fine to coarse, some fine gravel; arkosic with abundant quartz | 10 | 211 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic with abundant quartz; some pebbles of shale and limestone | 11 | 222 |
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 8 | 230 |
25-2W-35bcd--Sample log of Bentley reserve well no 1 in SE SW NW sec. 35, T 25 S, R 2 W, drilled by Layne-Western Co. for the City of Wichita, 1956. Altitude of land surface, 1,3747 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Recent stages (terrace deposits and alluvium) | |||
![]() |
![]() |
![]() |
Silt, very sandy, gray | 5 | 5 |
![]() |
![]() |
![]() |
Sand, fine | 5 | 10 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to coarse gravel; arkosic; fine gravel in lower 10 feet | 40 | 50 |
![]() |
Pliocene(?) Series and Lower Pleistocene Subseries, undifferentiated | ||||
![]() |
![]() |
![]() |
Sand, fine to coarse, fine to coarse gravel, grayish-pink; streaks of sandy tan silt | 5 | 55 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic, less gravel in lower 5 feet | 10 | 65 |
![]() |
![]() |
![]() |
Sand, fine to coarse, to very sandy tan to reddish-tan silt | 15 | 80 |
![]() |
![]() |
![]() |
Silt, sandy, tan; to fine to coarse sand and fine to medium gravel; arkosic | 10 | 90 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; arkosic; fine to coarse gravel in lower 5 feet with some material derived from the Dakota Formation | 15 | 105 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine to medium gravel; arkosic, with streaks of clayey tan silt | 15 | 120 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine gravel; arkosic, fine to coarse gravel in lower 10 feet | 15 | 135 |
![]() |
![]() |
![]() |
Sand, fine to coarse, to silt, clayey, sandy tan | 5 | 140 |
![]() |
![]() |
![]() |
Silt, clayey, sandy, to fine to coarse sand; arkosic | 5 | 145 |
![]() |
![]() |
![]() |
Silt, clayey, sandy, tan to grayish-tan; contains caliche and carbonaceous specks | 20 | 165 |
![]() |
![]() |
![]() |
Sand, fine; arkosic, much clayey tan silt | 5 | 170 |
![]() |
![]() |
![]() |
Silt, clayey, sandy, grayish-tan; much caliche | 5 | 175 |
![]() |
![]() |
![]() |
Silt, clayey, light-gray; many snail fragments in upper 5 feet | 10 | 185 |
![]() |
![]() |
![]() |
Sand, fine to coarse, fine to medium gravel, gray; limestone pebbles, chert, and sandy gray silt and clay streaks | 35 | 220 |
![]() |
![]() |
![]() |
Silt, sandy, gray; caliche and shale fragments in lower part | 2 | 222 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, dark-gray | 222 |
25-3W-7bbb--Sample log of test hole in NW NW NW sec. 7, T 25 S, R 3 W (Williams and Lohman 1949, p. 432); augered 1939. Altitude of land surface, 1,433.2 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
![]() |
![]() |
Soil | 4 | 4 |
![]() |
Pleistocene Series, undifferentiated | ||||
![]() |
![]() |
![]() |
Clay and silt, reddish-brown | 2 | 6 |
![]() |
![]() |
![]() |
Sand and gravel | 3 | 9 |
![]() |
![]() |
![]() |
Sand | 24 | 33 |
![]() |
![]() |
![]() |
Sand, contains clay balls | 2 | 35 |
![]() |
![]() |
![]() |
Sand and gravel | 12 | 47 |
![]() |
![]() |
![]() |
Gravel | 4 | 51 |
![]() |
![]() |
![]() |
Sand, coarse; interbedded with coarse gravel | 129 | 180 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Wellington Formation | |||
![]() |
![]() |
![]() |
Shale, gray | 20 | 200 |
25-3W-29cbb--Sample log of test hole in NW NW SW sec. 29, T 25 S, R 3 W in ditch on east side of road, 20 feet south of field drive, 30 feet south of 1/2-sec. fence; augered August 1957. Altitude of land surface, 1,453.0 feet; depth to water, 38.5 feet. | Thickness, feet |
Depth, feet |
|||
---|---|---|---|---|---|
Neogene | |||||
![]() |
Upper Pleistocene Subseries | ||||
![]() |
![]() |
Wisconsinan and Illinoisan stages (terrace deposits and loess, undifferentiated) | |||
![]() |
![]() |
![]() |
Silt, slightly sandy, dark-tan | 5 | 5 |
![]() |
![]() |
![]() |
Silt, grayish-tan | 5 | 10 |
![]() |
![]() |
![]() |
Silt, sandy, dark-tan to tan; with streaks of silty grayish-tan clay | 35 | 45 |
![]() |
![]() |
![]() |
Silt, tan; much fine sand; with fine to coarse silty sand at base | 10 | 55 |
![]() |
![]() |
![]() |
Sand, fine to coarse, and fine to medium gravel; arkosic | 16 | 71 |
Permian | |||||
![]() |
Lower Permian Series | ||||
![]() |
![]() |
Ninnescah Shale | |||
![]() |
![]() |
![]() |
Shale, red | 71 |
T. 25 S. || T. 26 S. || T. 27 S. || T. 28 S. || T. 29 S. || T. 30 S.
Kansas Geological Survey
Placed on web March 8, 2012; originally published in December 1965.
Comments to webadmin@kgs.ku.edu
The URL for this page is http://www.kgs.ku.edu/Publications/Bulletins/SDP22/index.html
