Southeast Kansas Coal Geology Field Trips

Kansas Geological Survey Open-file Report 2002-27

Larry Brady, Lee Allison and Marty Dubois standing at field office for Devon east of Chanute.

The 600 hp compressor used by Devon to move gas through a 3 mile long 12” diameter gathering line. The compressor is capable of moving 100 MMCF/D. The 12” taps into the 30” Williams line just to the west (100 yards).

The 600 hp compressor used by Devon to move gas through a 3 mile long 12” diameter gathering line. The compressor is capable of moving 100 MMCF/D. The 12” taps into the 30” Williams line just to the west (100 yards).

View looking east down the 3 mile long gathering line (12” diameter). Wells are just visible and are spaced at 160 acres. They use 5-1/2” casing and pump water up the tubing. The gas comes up the annulus.

View looking east down the 3 mile long gathering line (12” diameter). Wells are just visible and are spaced at 160 acres. They use 5-1/2” casing and pump water up the tubing. The gas comes up the annulus.

From right Marty Dubois, Larry Brady (KGS). ???? Devon), Lee Allison (KGS) Jim Smith and Wayne Roberts (Devon). The 600 hp compressor is used by Devon to move gas through a 3 mile long 12” diameter gathering line. The compressor is capable of moving 100 MMCF/D. The 12” taps into the 30” Williams line just to the west (100 yards).

Connection of Devon 12” gather line with the Williams 30” trunk line.
