The Role of Moldic Porosity in Paleozoic Kansas Reservoirs and the Association of Original Depositional Facies and Early Diagenesis With Reservoir Properties

Kansas Geological Survey
Open-file Report 2003-32

Facies (3) Peloidal packstone-grainstone (Non-reservoir)

#11-05 Truesdell 3246.3’

Peloidal packstone with clotted fabric,
#1 Madsen 3354’, plane polarized light.

Typically massive, horizontally laminated or bedded and commonly interbedded with coarser-grained lithologies. Locally, it contains wispy lenses of shale and interbedded shale layers. Burrow traces and mottling are common. Peloids are abundant and rare interclasts, lumps, and skeletal grains (gastropods) are present. Soft sediment deformation, dewatering or teepee-like structures, mudcracks, and rip-up clasts are locally associated with this facies. The mud-rich peloidal packstone/grainstone facies represents deposition in relatively lower-energy subtidal and peritidal environment. This rock is tightly bound consisting of anhedral, euhedral, and polyhedral dolomite (< 0.5 mm) and peloidal cement.
