Kansas Geological Survey, Bulletin 165, pt. 4, originally published in 1963
Originally published in 1963 as Kansas Geological Survey Bulletin 165, pt. 4. This is, in general, the original text as published. The information has not been updated. An Acrobat PDF version (1.3 MB) is also available.
The Kansas Basement Rocks Committee of the Kansas Geological Society, in cooperation with the State Geological Survey of Kansas, is continuing an active research program on Precambrian basement rocks. A list of 112 wells, in addition to those previously published, that penetrate the buried Precambrian basement in Kansas is presented. The number of wells known to encounter the basement as of December 31, 1962, is about 2,300.
Increased interest in the Precambrian basement in recent years has resulted in numerous studies of these rocks which form a rigid, complex "floor" beneath the overlying sedimentary sequence. Since its formation in 1958, the Kansas Basement Rocks Committee of the Kansas Geological Society, in cooperation with the State Geological Survey of Kansas, has been collecting information pertaining to the basement. To date, data on more than 2,300 wells reaching the buried basement have been tabulated and published so that they are readily available. This report is one of the series of such publications.
In addition to tabulating information on wells penetrating the Precambrian basement in Kansas, the Committee is actively collecting well cuttings and cores for analysis and preservation for future study. Selected samples will be studied for information on rock type, magnetic susceptibility, density, and radioactive age dates. These data can then be analyzed to gain understanding of the relations between the surface magnetic and gravity values and the configuration and distribution of basement rocks, to resolve the age of the basement complex, and perhaps to allow grouping of the rocks into meaningful units to help interpretation of their complex history. A knowledge of the basement will also be useful in understanding waves transmitted through the earth and recorded at seismograph stations.
It is possible that undetected mineral deposits of potential commercial value occur in the buried Precambrian rocks of Kansas. Only the closest scrutiny could reveal iron ore such as the Pea Ridge deposit found in Missouri's Precambrian several years ago. For many years, oil has been known to occur in fractures in Precambrian rocks, and it is produced in several fields in the central part of the state on the Central Kansas Uplift. Approximately 0.5 percent of Kansas' cumulative oil production has come from reservoirs in Precambrian rock. Exploration, and especially exploitation, of the Precambrian basement will be difficult, but the potential rewards warrant such investigations.
We would like to acknowledge the continuing support of the Kansas Geological Society and of the many individuals and companies that have graciously supplied information and samples. A list of Precambrian wells maintained by the Oil and Gas Division of the Kansas Survey, of information reported by Data, Incorporated, was especially useful for checking the list prepared for this report. Miss Sally S. Liggett of the Kansas Geological Survey helped assemble and check the information on the wells.
Several preliminary and progress reports have been issued by members of the committee:
These reports indicate the general nature of the Precambrian rocks, but many aspects of the Kansas basement need to be studied.
Currently, members of the Kansas Basement Rocks Committee are engaged in directing several projects. Petrography and petrology of the. basement rocks are being investigated in some detail. Stratigraphy of beds overlying the Precambrian is being studied. Potassium-argon age dates have been determined for several samples and soon will be reported in print by J. L. Kulp. A bibliography of publications dealing with the Precambrian in Kansas is being compiled. Wells producing from the Precambrian and their production history are being listed.
For ease in handling and updating data, all Precambrian well information is being transcribed to punch cards for processing by high-speed, electronic digital computers. Several projects utilizing electronic data processing are under consideration; preliminary investigations have been generously supported by The University of Kansas Computation Center, R. G. Hetherington, Director.
The task of collecting information is never ending, and donations of cores or cuttings are always gratefully accepted. The information is kept on file in the offices of the Kansas Survey at The University of Kansas, Lawrence, and the data made available to all interested students of Precambrian geology.
The following list (Table 1) contains information for each well as to county, company and farm name, location, surface elevation, depth to Precambrian, Precambrian datum, rock type, rock unit on basement, and total depth. The wells are arranged by township and range, west ranges listed first. Information is presented in the same format as that in the earlier publications.
These data have been collected from a variety of sources including electric and radioactivity logs, top cards, drillers logs, sample logs, and logs of the Kansas Sample Log Service. For verification, information was checked from two sources wherever possible. The list includes not only boreholes completed in 1962, but some older wells omitted from the previous lists. Any additions, corrections, or omissions noted should be addressed to the Kansas Survey.
All information has been forwarded to the American Association of Petroleum Geologists Basement Rocks Project Committee, P. T. Flawn, Chairman, and to the basement rocks project of the Advanced Research Projects Agency, W. R. Muehlberger, Director.
Table 1—Additional boreholes drilled to Precambrian rocks in Kansas.
County | Company, well number, and farm |
Location | Surface elevation, feet |
Depth to Precambrian, feet |
Elevation of Precambrian, feet |
Precambrian rock type |
Rock unit on basement |
Total depth, feet |
---|---|---|---|---|---|---|---|---|
Norton | Terrel & Nat'l. No. 1 Melroy |
19-1-23W NW NW NW |
2411 | 3594 | -1183 | 19 ft. granite wash on granite |
Pennsylvanian | 3623 |
Norton | Raymond No. 1 Sauer |
31-1-23W C SW NW |
2472 | 3707 | -1235 | 35 ft. granite wash on granite |
Pennsylvanian | 3771 |
Norton | Raymond No. 1 McKinley |
15-1-24W C NW NW |
2373 | 3551 | -1178 | 7 ft. granite wash on granite |
Marmaton | 3566 |
Norton | Geochemical No. 1 Scrivner |
8-1-25W C SE NE |
2394 | 3570 | -1176 | 39 ft. granite wash on granite |
Pennsylvanian | 3618 |
Norton | Geochemical No. 1 Jenkins |
9-1-25W C NE SW |
2341 | 3532 | -1191 | 14 ft. granite wash on granite |
Pennsylvanian | 3560 |
Norton | Champlin No. 1 Railsback |
15-1-25W C NW NE |
2403 | 3573 | -1170 | 33 ft. granite wash on granite |
Pennsylvanian | 3606 |
Decatur | Walker No. 1 Huff |
10-1-26W C NE SE |
2493 | 3591 | -1098 | 15 ft. granite wash on granite |
Pennsylvanian | 3618 |
Decatur | Sauvage No. 1 Cozad |
11-1-26W C NW SE |
2440 | 3582 | -1142 | 20 ft. granite wash on granite |
Pennsylvanian | 3612 |
Decatur | Chem. & Tech. No. 1 Knutson |
11-1-26W C SE NW |
2477 | 3606 | -1129 | 19 ft. granite wash on granite |
Pennsylvanian | 3631 |
Decatur | Murfin & Ainsworth No. 1 Bremmer |
18-1-26W NW NW NW |
2500 | 3591 | -1091 | granite | Marmaton | 3602 |
Decatur | Sauvage No. 1 Mizell |
25-1-26W SW SW NW |
2518 | 3747 | -1229 | 15 ft granite wash on granite |
Pennsylvanian | 3769 |
Decatur | Sauvage No. 2 Kilzer |
2-1-27W C NW NE |
2605 | 3674 | -1069 | 19 ft. granite wash on granite |
Pennsylvanian | 3702 |
Decatur | Sauvage No. 1 McQuillan |
23-1-27W C NW NE |
2433 | 3565 | -1132 | granite | Reagan | 3582 |
Decatur | Kidd No. 1 McQuillan |
23-1-27W NW NW NW |
2475 | 3554 | -1079 | granite wash | Marmaton | 3560 |
Decatur | Rains & Williamson No. 1 Metcalf |
33-1-27W C NW NW |
2486 | 3600 | -1114 | granite | Pennsylvanian | 3608 |
Decatur | Sauvage No. 1 Smalberger |
4-1-28W NE NE SE |
2651 | 3893 | -1242 | 8 ft. granite wash on granite |
Reagan | 3906 |
Decatur | Rains and Williamson No. 1 Waldo |
23-1-30W C SW SW |
2672 | 4332 | -1660 | 19 ft. granite wash on granite |
Reagan | 4356 |
Rawlins | Murfin & Ladmer No. 1 Stolte |
6-1-32W C NW NW |
2847 | 4549 | -1702 | 15 ft. granite wash on granite |
Reagan | 4576 |
Norton | Pubco No. 16-13 Drommer |
16-2-22W C SW SW |
2324 | 3733 | -1409 | 4 ft. granite wash on granite |
Arbuckle | 3739 |
Norton | Reading & Bates No. 1 Lecount |
1-2-25W C SE NW |
2477 | 3688 | -1211 | 13 ft. granite wash on granite |
Pennsylvanian | 3712 |
Norton | Cities Service No. 1 Curran |
11-2-25W C NE NE |
2510 | 3734 | -1224 | 8 ft. granite wash on granite |
Reagan | 3762 |
Norton | C & G and Shields No. 1 Rubendall |
35-2-25W NE NE NW |
2500 | 3845 | -1345 | granite | Reagan | 3855 |
Decatur | Farmer No. 1 Thomsen |
1-2-28W C NE NW |
2580 | 3992 | -1412 | granite | Arbuckle | 4001 |
Decatur | Sauvage No. 1 Smick |
9-2-28W C NW NW |
2643 | 4135 | -1492 | granite | Arbuckle | 4138 |
Decatur | Murfin & Donnelly No. 1 Miller |
12-2-28W C NE SW |
2490 | 3930 | -1440 | 32 ft. granite wash on granite |
Arbuckle | 4040 |
Decatur | Rock Island No. 1 Reeves |
12-2-28W C SW NE |
2488 | 3904 | -1416 | 8 ft. granite wash on granite |
Reagan | 3940 |
Norton | Terrel & Pentagon No. 1 Henderson |
4-3-23W NW SE SE |
2251 | 3536 | -1285 | 10 ft. granite wash on granite |
Reagan | 3552 |
Norton | Barker No. 1 Moody |
22-3-23W NE NW NE |
2408 | 3718 | -1310 | 14 ft. granite wash on granite |
Pennsylvanian | 3769 |
Norton | Glickman No. 2 Horning |
30-3-23W N2 N2 NE |
2447 | 3772 | -1325 | granite wash | Lansing-Kansas City | 3805 |
Norton | Harms & Riggs No. 1 Davis |
19-3-24W S2 SE NE |
2331 | 3636 | -1305 | 30 ft. granite wash on granite |
Reagan | 3676 |
Norton | C & G and Shields No. 1 "A" Ankenman |
29-3-24W NE NE SE |
2346 | 3678 | -1332 | 47 ft granite wash on granite |
Reagan | 3730 |
Norton | Continental No. 1 Hemphill |
8-4-22W NE NE SW |
2370 | 3866 | -1496 | 14 ft. granite wash on granite |
Reagan | 3903 |
Norton | Colorado No. 1 Foss |
32-4-22W NE NW NW |
2235 | 3712 | -1477 | 14 ft. granite wash on granite |
Reagan | 3727 |
Norton | Petroleum No. 1 Browne |
25-4-23W C NW NW |
2360 | 3748 | -1388 | 59 ft. granite wash on granite |
Pennsylvanian | 3810 |
Norton | Sterling No. 1 Shewey |
29-4-23W C SE SE |
2437 | 3980 | -1543 | 9 ft. granite wash on granite |
Reagan | 3997 |
Norton | Continental No. 1 Wiltfong |
9-4-24W NW NW NW |
2485 | 3905 | -1420 | 25 ft. granite wash on granite |
Reagan | 3952 |
Phillips | Cities Service No. 1 Kowitz |
18-5-20W W2 NE SE |
2128 | 3750 | -1622 | granite wash | Reagan | 3761 |
Phillips | Messman-Rinehart No. 1 Steele Estate |
34-5-20W SW SW NE |
2100 | 3676 | -1576 | granite | Reagan | 3680 |
Phillips | Cities Service No. 1 "B" Wiltrout |
36-5-20W NE NE SW |
2064 | 3620 | -1556 | quartzite | Reagan | 3630 |
Norton | Ainsworth No. 1 Fitzsimmons |
4-5-22W C SE SE |
2198 | 3634 | -1436 | 26 ft. granite wash on granite |
Reagan | 3674 |
Norton | D & D No. 1 Krehbiel |
24-5-22W C SE NW |
2300 | 3737 | -1437 | granite wash | Reagan | 3765 |
Norton | Antry & Warren No. 1 McKinley |
26-5-22W SW SW SE |
2235 | 3748 | -1513 | granite wash | Marmaton | 3780 |
Rooks | Hoover No. 1 Steel Estate |
9-6-20W C SW NW |
2162 | 3624 | -1462 | weathered granite | Pennsylvanian | 3630 |
Rooks | Veverka No. 1 Hance |
13-8-19W C SE SW |
2009 | 3700 | -1691 | 14 ft. granite wash on granite |
Arbuckle | 3720 |
Rooks | Cities Service No. 2 Rempe (OWWO) |
21-9-18W SE SW SE |
2164 | 4099 | -1935 | granite wash | Reagan | 4108 |
Rooks | Cities Service No. 4 "U" Smith |
15-10-16W SW NW SE |
2003 | 3765 | -1762 | 3 ft. granite wash on granite |
Reagan | 3798 |
Ellis | Sunray No. 1 Hadley |
13-11-18W N2 NE NW |
1860 | 3898 | -2038 | granite wash | Reagan | 3909 |
Ellis | Dreiling No. 11 "A" Dreiling |
13-12-16W NW NW NE |
1806 | 3702 | -1896 | granite wash | Arbuckle | 3705 |
Russell | Home-Stake No. 0-16 Linenberger |
33-13-15W C NE SW |
1897 | 3372 | -1475 | 4 ft. granite wash on granite |
Reagan | 3382 |
Ellis | Dreiling No. 1 "D" Staab |
7-13-17W NE NW NW |
2047 | 3915 | -1868 | granite | Arbuckle | 3916 |
Trego | Murfin No. 4 Cromb |
1-13-21W NE NW SE |
2171 | 3904 | -1733 | dunite? granite? |
Reagan | 3906 |
Russell | Dreiling No. 2 Krug |
4-14-14W C SE |
1835 | 3319 | -1484 | granite wash | Reagan | 3339 |
Russell | Kim No. 1 Krug |
17-14-14W SE SW NW |
1877 | 3313 | -1436 | granite wash | Pennsylvanian | 3326? |
Russell | Phillips No. 3 Carrie |
18-14-14W SE NW NE |
1871 | 3309 | -1438 | granite wash | Arbuckle | 3320 |
Russell | Melton No. 2 Hall |
21-14-14W E2 NW SE |
1851 | 3267 | -1416 | granite wash | Lansing-Kansas City | 3290 |
Russell | Home-Stake No. 0-15 "E" Witt |
3-14-15W C NE SW |
1884 | 3286 | -1402 | granite wash | Lansing-Kansas City | 3307 |
Russell | Home-Stake No. 0-19 Dortland |
4-14-15W C SW NW |
1896 | 3287 | -1391 | granite wash | Marmaton | 3348 |
Russell | Home-Stake No. 0-20 Dortland |
4-14-15W C SE NW |
1878 | 3264 | -1386 | granite wash | Marmaton | 3316 |
Russell | Home-Stake No. 0-14 "D" Witt |
4-14-15W C SE SE |
1884 | 3280 | -1396 | granite wash | Marmaton | 3300 |
Russell | Birmingham-Bartlett No. 3 "A" Driscoll |
19-15-11W W2 W2 SW |
1858 | 3264 | -1406 | quartzite | Lansing-Kansas City | 3269 |
Russell | Nixon No. 1 Herber |
19-15-11W SW NW SE |
1859 | 3305 | -1446 | granite wash | Lansing-Kansas City | 3311 |
Russell | Dreiling No. 2 Heinze |
24-15-12W E2 E2 SE |
1866 | 3269 | -1403 | quartzite | Lansing-Kansas City | 3274 |
Russell | Dreiling No. 1 Janne |
24-15-12W C SW NE |
1852 | 3269 | -1417 | quartzite | Lansing-Kansas City | 3273 |
Russell | Birmingham-Bartlett No. 2 "G" Staudinger |
26-15-12W S2 S2 NW |
1837 | 3221 | -1384 | quartzite | Lansing-Kansas City | 3222 |
Russell | Farmer No. 4 Buehler |
26-15-12W N2 N2 SW |
1837 | 3182 | -1345 | quartzite | Lansing-Kansas City | 3197 |
Rush | Frontier No. 1 Kansas State |
6-16-17W NE NE SE |
1927 | 3633 | -1706 | granite wash | Reagan | 3637 |
Rush | Frontier No. 1 "A" Stegman |
22-16-17W SW NE SE |
2009 | 3730 | -1721 | quartzite on granite | Reagan | 3744 |
Barton | Magnolia No. 3 "A" Grossard |
9-17-11W C SW NW |
1841 | 3467 | -1626 | granite wash | Arbuckle | 3526 |
Rush | Petroleum No. 1 "B" Giesick |
19-17-16W SE NW NW |
2018 | 3500 | -1482 | granite wash | Lansing-Kansas City | 3540 |
Rush | Northern Natural No. 1 "A" Rothe |
30-17-16W SE NW SE |
2034 | 3565 | -1531 | weathered granite | Lansing-Kansas City | 3604 |
Rush | Frontier No. 2 McGill |
3-17-17W C SW |
2077 | 3600 | -1523 | granite wash | Lansing-Kansas City | 3633 |
Rush | Frontier No. 1 Frye |
4-17-17W C NE |
2057 | 3588 | -1531 | granite wash | Lansing-Kansas City | 3619 |
Rush | Northern Natural No. 1 "A" Grumbien |
9-17-17W SW SE NE |
2080 | 3592 | -1512 | 10 ft. granite wash on granite |
Lansing-Kansas City | 3620 |
Rush | Frontier No. 1 Appl |
10-17-17W NW SE NW |
2066 | 3565 | -1499 | granite wash | Lansing-Kansas City | 3573 |
Rush | Northern Natural No. 1 Hondrick |
10-17-17W NW SE NE |
2067 | 3582 | -1515 | 24 ft. granite wash on granite |
Lansing-Kansas City | 3609 |
Rush | Frontier No. 1 Rau |
10-17-17W NW SE SE |
2059 | 3567 | -1508 | granite wash | Lansing-Kansas City | 3600 |
Rush | Petroleum No. 1 "K" Schneider |
13-17-17W NE SW SE |
2044 | 3537 | -1493 | 47 ft. granite wash on granite |
Pennsylvanian | 3590 |
Rush | Frontier No. 1 "A" Ernie |
14-17-17W NW NE NE |
2053 | 3557 | -1504 | granite | Lansing-Kansas City | 3575 |
Rush | Frontier No. 1 "A" Foos |
22-17-17W SW NE NE |
2070 | 3575 | -1505 | 6 ft. granite wash on granite |
Lansing-Kansas City | 3608 |
Rush | Frontier No. 1 Foos |
25-17-17W NE SW SE |
2007 | 3500 | -1493 | granite wash | Lansing-Kansas City | 3531 |
Rush | Frontier No. 1 Erbes |
26-17-17W NE SW SE |
2041 | 3559 | -1518 | granite wash | Lansing-Kansas City | 3578 |
Rush | Frontier No. 1 Neuhauser |
27-17-17W W2 W2 NE |
2031 | 3545 | -1514 | granite wash | Lansing-Kansas City | 3560 |
Rush | Morrison No. 1 Wagner |
33-17-17W W2 NW NE |
2015 | 3580 | -1565 | 10 ft. granite wash on granite |
Pennsylvanian | 3592 |
Rush | Frontier No. 1 Beahm |
36-17-17W W2 E2 NE |
1999 | 3495 | -1496 | granite wash | Lansing-Kansas City | 3540 |
Rush | Frontier No. 1 Scheuerman |
36-17-17W SW NE SE |
1997 | 3501 | -1504 | granite wash | Lansing-Kansas City | 3613 |
Rush | Petroleum No. 1 Kahler |
20-17-18W C NE NW |
2118 | 3801 | -1683 | granite wash | Pennsylvanian | 3822 |
Barton | Alpine No. 4 Blankenship |
20-18-13W SW SW SW |
1905 | 3710 | -1805 | granite wash | Arbuckle | 3730 |
Barton | Shirer No. 5 McCauley |
12-18-14W SW SE NE |
1866 | 3520 | -1654 | granite wash | Arbuckle | 3551 |
Rush | Morrison No. 1 Dirks |
7-18-16W NW SE SE |
1950 | 3515 | -1565 | 26 ft. granite wash on weathered granite |
Reagan | 3554 |
Rush | Morrison No. 1 Schneider |
17-18-16W SE NW NW |
1950 | 3530 | -1580 | granite wash | Reagan | 3535 |
Rush | Morrison No. 2 Huenergardt |
18-18-16W SE NE SE |
1949 | 3546 | -1597 | granite wash | Reagan | 3585 |
Rush | Morrison No. 1 Pechanec |
18-18-16W SE SW NE |
1951 | 3566 | -1615 | granite | Reagan | 3606 |
Rush | Woodman & Iannitti No. 1 Green |
17-18-17W C NE SW |
1997 | 4007 | -2010 | granite | Reagan | 4009 |
Barton | Glickman-Houston & Seeber No. 1 Pasco |
10-19-15W SE SE SE |
1933 | 3488 | -1555 | granite wash | Reagan | 3504 |
Barton | Nixon No. 2 Schartz |
26-J9-15W SW SW SW |
1922 | 3480 | -1558 | quartzite | Lansing-Kansas City | 3482 |
Barton | Bove No. 5 Button |
35-19-15W E2 NE NW |
1920 | 3565 | -1645 | quartzite | Pennsylvanian | 3574 |
Barton | Nixon No. 1 "B" Ewing |
36-19-15W NW SW SW |
1942 | 3503 | -1561 | quartzite | Reagan | 3506 |
Barton | Petroleum No. 1 "B" Hiss |
32-20-13W SE SE SE |
1897 | 3560 | -1663 | quartzite | Arbuckle | 3617 |
Edwards | White & Wilkenson No. 1 Reaves |
1-24-16W S2 SW NW |
2053 | 3976 | -1923 | 54 ft. weathered granite on granite |
Lansing-Kansas City | 4038 |
Pratt | Continental No. 6 Brehm |
23-28-13W NE SW SW |
1956 | 5072 | -3116 | granite wash | Reagan | 5150 |
Riley | Valentin No. 1 Kunze |
33-6-5E C NE SE |
1141 | 2462 | -1321 | granite | Simpson | 2547 |
Riley | Phillips No. 1 Winkler |
8-6-6E C SE NE |
1413 | 2584 | -1171 | amphibolite? | Simpson | 2735 |
Riley | Pawnee No. 1 Marks |
26-10-6E SW NE NW? |
1213 | 2400? | -1187? | granite | Simpson? | 2445 |
Riley | Johnston No. 1 Deep Creek Ranch |
32-10-9E SW NW SW |
1105 | 1078 | +27 | granite | Pennsylvanian | 1094 |
Riley | Johnston No. 1 Hayden |
34-10-9E SW NW SW |
1120? | 1070 | +50? | granite | Marmaton | 1089 |
Riley | Johnson No. 1 Moore |
6-11-9E SE SE SW |
1055 | 1124 | -69 | granite | Marrnaron | 1130 |
Riley | Johnson No. 1 Newell Estate |
6-11-9E SW SE SW |
1070 | 1147 | -77 | granite | Marmaton | 1183 |
Riley | Johnson No. 1 "B" Durein |
15-11-9E NW SW SE |
1390 | 1438 | -48 | granite | Marmaton | 1452 |
Morris | Rex & Morris and Mobil No. 1 Buchman |
4-14-8E C NE NE |
1525 | 2424 | -899 | granite | Arbuckle | 2428 |
Morris | Forrester No. 1 Mangle |
6-17-7E NW NW SE |
1538 | 2300? | -762? | granite | Arbuckle? | 2560 |
Butler | Empire No. 30 Murphy |
31-25-5E SW SE NE |
1387 | 3285? | -1898? | dark basic igneous rocks |
Arbuckle | 3375 |
Cowley | Texaco No. 4 Goodrich |
21-31-4E NW SW SE |
1211 | 4187 | -2976 | granite | Arbuckle | 4188 |
Kansas Geological Survey
Placed on web Dec. 4, 2018; originally published in December 1963.
Comments to webadmin@kgs.ku.edu
The URL for this page is http://www.kgs.ku.edu/Publications/Bulletins/165_4/index.html
